Alcatel-Lucent 8DG60352AA 03 100G Transponder Module

Description

3. Key Technical Specifications

4. Product Introduction & Supply Chain Strategy

The Alcatel-Lucent 8DG60352AA 03 is a cornerstone of the 1830 PSS (Photonic Service Switch) ecosystem, providing the high-speed 100G coherent transport required for modern fiber-optic backbones. This module handles the conversion of client-side signals into long-haul DWDM wavelengths, utilizing advanced Forward Error Correction (FEC) to maintain signal integrity over thousands of kilometers.

From a supply chain perspective, the 8DG60352AA 03 is a high-capital asset. Maintaining a New Surplus unit on-site serves as an essential insurance policy against backbone outages. Unlike refurbished optical cards, which may have degraded lasers or compromised internal cooling fans, our New Surplus units provide the full 15+ year reliability profile expected of Tier-1 carrier equipment. Avoiding a single day of network downtime pays for the cost of this spare multiple times over, securing a superior Total Cost of Ownership (TCO) compared to the risks of used hardware.

8DG60352AA 03

5. Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

Verify that the 1830 PSS shelf has sufficient power budget and cooling capacity for a 100G card. Use a high-quality fiber inspection microscope to ensure all patch cables are free of contaminants. Mandatory: Wear a grounded ESD wrist strap; 100G optics are extremely sensitive to static.

Stage 2: Removal

If replacing an existing 8DG60352AA, first “lock” the administrative state of the card via the network management system (NMS). Gently unlatch the card handles and pull the unit straight out of the guide rails to avoid damaging the high-density backplane pins.

Stage 3: Installation (Clone & Seat)

Inspect the 8DG60352AA 03 for any physical debris. Slide the module into the designated slot until the handles meet the shelf frame. Simultaneously close both handles to fully seat the card into the backplane connectors.

Stage 4: Power-On & Testing

Observe the module’s LED sequence. The “Power” LED should be green, and the “Fault” LED should extinguish after the internal POST (Power-On Self-Test). Connect to the NMS to provision the wavelength and verify that the Pre-FEC Bit Error Rate (BER) is within acceptable carrier limits.

6. Firmware/Software Versions & Upgrade Notes

The 8DG60352AA 03 requires a compatible version of the 1830 PSS software (typically Release 8.2 or later). Ensure the shelf controller’s database recognizes the specific hardware revision “03” before attempting to pass live traffic.

Critical Note: When swapping cards, the system may attempt an automatic firmware download (FWDL) to match the shelf’s current software load. Do not interrupt power or pull the card during this 10–15 minute process, as it can corrupt the onboard flash memory.

7. Frequently Asked Questions (FAQ)

What does the “03” at the end of the part number signify?

The “03” represents the hardware revision level. In high-speed optical networking, matching revision levels is vital for ensuring consistent performance and compatibility with specific backplane architectures.

Is this a “New Surplus” unit or a “Refurbished” one?

This is 100% New Surplus. It has remained in controlled storage and has never been commissioned in a live network. It is not “Used” or “Factory Repaired,” ensuring the optical laser has zero hours of service wear.

Why is it important to buy “New” for 100G transponders?

100G coherent optics rely on highly sensitive laser components and high-speed DSPs (Digital Signal Processors). Refurbished units often come from decommissioned environments where they were subjected to years of heat and power cycles, significantly increasing the probability of a “latent failure” shortly after installation.

Can I use this card in a PSS-16 shelf?

Yes, the 8DG60352AA 03 is designed for the 1830 PSS family and is compatible with PSS-32, PSS-16, and PSS-8 shelves, provided the shelf is running a compatible software release.

Does the module include the SFP/QSFP optics?

This part number refers to the base transponder line card. Depending on the original packaging, client-side optics (pluggables) may need to be ordered separately to match your specific distance requirements (SR4, LR4, etc.).
