GE IC693ALG391 2-Channel Analog Output Module

Description

In control cabinets overseeing chemical reactors, conveyor speed regulation, or HVAC damper actuators, the GE IC693ALG391 handles the critical task of driving field devices with precise analog signals, preventing overruns or underperformance that cascade into production halts. Process engineers deploy it in water utilities adjusting chlorination pumps based on flow feedback, or in packaging lines modulating filler valves to match throughput—environments where two channels of scalable current or voltage output must hold steady amid voltage dips and load swings from nearby machinery. This module tackles common headaches like signal droop over long runs or compliance with 4-20 mA standards, ensuring valves, drives, and recorders get clean commands without external amplifiers eating panel space.​

Picture a batch plant where PLC logic calculates setpoints from upstream sensors: the GE IC693ALG391 translates those into 0-20 mA bursts for proportional control, updating in under a scan cycle to keep reactions on track. It’s a staple in Series 90-30 systems for oil refineries positioning louvers or food processors tuning extruders, where dual outputs mean balancing two loops per slot and simplifying wiring diagrams for maintenance crews. In industrial automation demanding loop-powered devices or voltage-driven servos, the GE IC693ALG391 cuts through noise with optical barriers and configurable scaling, letting operators focus on uptime rather than chasing erratic actuator behavio​

Product Introduction & Positioning

The GE IC693ALG391 functions as a two-channel analog output module for GE Fanuc Series 90-30 PLCs, converting 16-bit digital commands from the CPU into selectable current (0-20 mA or 4-20 mA) or voltage (0-5 VDC or 1-5 VDC) signals for field actuators and transmitters. It installs in any I/O slot on standard baseplates, pulling isolated power from the backplane while providing screw terminals for direct field wiring, complete with short-circuit protection to safeguard loops. Within a Series 90-30 architecture, it complements input modules like voltage readers, closing the loop on PID controls or setpoint distribution without taxing CPU resources on custom scaling.​

For system builders, the GE IC693ALG391 offers flexibility in mixed-signal racks, where engineers map %AQ words via simple configuration and switch modes per channel for hybrid voltage-current setups common in legacy upgrades. Positioned as a compact, versatile output handler, it suits expansions on existing 90-30 panels or new distributed control where density matters more than channel count. Integrators appreciate its drop-in compatibility with Proficy tools for ramping, fault reporting, and diagnostics, making it a reliable choice for standardizing analog drive in process-heavy installs.

​

Key Technical Features & Functional Benefits

Each channel on the GE IC693ALG391 resolves to roughly 0.3 microamps in current mode or 76 microvolts in voltage, with update times syncing to PLC scans for responsive loop performance in tuning-sensitive applications. Accuracy holds to 0.3% of span, bolstered by onboard diagnostics that flag opens, shorts, or underranges via status bits, so operators catch issues before they ripple through the process. This precision supports engineering units directly, like scaling counts to PSI for hydraulic valves, without floating-point overhead.​

Built tough, the GE IC693ALG391 isolates at 1500 volts field-to-logic, handling common-mode voltages and capacitive loads up to 2000 pF while driving resistive loads to 600 ohms in current mode. Power draw stays low—five watts max from the 24 VDC isolated supply—fitting tight budgets in multi-module racks, with front LEDs signaling channel health and a half-rack footprint for dense layouts. Screw terminals accept 14-22 AWG wire, and built-in fusing prevents loop damage from wiring faults.​

Reliability shines in continuous duty, with no calibration drift over years and support for loop powering that extends cable reaches in large facilities. The GE IC693ALG391 excels where integrators need fault-tolerant outputs that integrate smoothly with discrete and high-speed modules, often forming the output half of transducer pairs in closed-loop schemes.​

Detailed Technical Specifications

Related Modules or Compatible Units

IC693ALG392 – Four-channel version in the same Series 90-30 lineup, expanding output capacity when the GE IC693ALG391‘s dual channels fall short.​

IC693ALG220 – Voltage input module often paired with the GE IC693ALG391 to form complete analog loops in process racks​

IC693CPU364 – Entry-level Series 90-30 CPU that drives the GE IC693ALG391 effectively for smaller PID-heavy applications.​

IC693PWR322 – High-capacity power supply ensuring stable 24 VDC for multiple GE IC693ALG391 outputs in loaded baseplates​

IC693CHS390 – Five-slot expansion baseplate housing the GE IC693ALG391 alongside remote I/O linkers for plant-wide distribution.​

IC693ALG223 – Eight-channel current source companion, used with the GE IC693ALG391 for high-density output needs.​

IC694ALG391 – PACSystems equivalent, bridging upgrades from GE IC693ALG391-based 90-30 systems.​

Installation Notes & Maintenance Best Practices

Panel planners for the GE IC693ALG391 should tally isolated 24 VDC headroom across all analog outputs, routing loop wires through dedicated glands to isolate from discrete signals and respecting 50 mm separation from power cabling. Pre-commission torque checks on terminals prevent cold joints, and verifying load resistance pre-powerup avoids overload trips—common gotcha with inductive actuators. For daisy-chained loops, add suppression diodes if specs call for it, and document channel modes in as-builts since field swaps can mismatch configurations.​

Quarterly routines for GE IC693ALG391-equipped racks involve scanning fault LEDs and %AQ status via HMI, cross-checking outputs with a calibrator to confirm no drift from heat or vibration. Cable inspections focus on shield continuity and insulation cracks, especially in washdown areas, while Proficy logs help trend underrange events tied to failing field devices. Module replacement needs only backplane power down, with no reconfiguration beyond slot remapping, keeping outages under 15 minutes.
