GE IC693ALG392-BE Analog Output Module

Description

Product Introduction & Positioning
The IC693ALG392-BE is a VersaMax analog output module with up to eight independent channels. It plugs into the VersaMax backplane alongside other I/O and processing modules, providing configurable current or voltage outputs to drive actuators, valves, and other analog devices. This module is well-suited for retrofit projects and new installations within established GE automation footprints, offering familiar programming models and straightforward integration with the VersaMax ecosystem. The model IC693ALG392-BE is often chosen for its channel density, reliable performance, and compatibility with existing GE Fanuc software tools, making it a dependable cornerstone for mid-range control systems.

Key Technical Features & Functional Benefits
The IC693ALG392-BE focuses on reliable, multi-channel analog output with per-channel configurability. Expect independent channel operation with flexible ranges for voltage or current signals, enabling a mix of sensor-driven and actuator-driven control strategies. Isolation between channels and from the backplane helps protect the controller from noise and faults, improving overall system robustness. Update rates and resolution on each channel support precise motion or process control, while diagnostics give hardware-level visibility to flag failed channels or wiring issues. When integrated with the VersaMax IO family, this module contributes to a cohesive, scalable control fabric with predictable performance across production runs.

Detailed Technical Specifications
Parameter Value
Model IC693ALG392-BE
Brand GE Fanuc VersaMax Emerson
Type Analog Output Module
Channels 1 to 8 configurable
Output Types Voltage or Current
Output Range Configurable per channel (e.g., 0–10 V, ±10 V, 4–20 mA)
Isolation Per Channel Yes
Resolution 12–16-bit depending on range and firmware
Backplane Compatibility VersaMax backplane
Power Requirements Backplane power plus any local supply if applicable
Operating Temperature Range Industrial range (exact values to be confirmed)
Mounting VersaMax chassis backplane or compatible enclosure
Dimensions (to be confirmed)
Weight (to be confirmed)
Certifications CE, UL, RoHS (region-specific)
Update Rate 8–10 ms per channel (typical; exact depends on scan time)
