The Honeywell 05701-A-0293 appears to be a control card used within Honeywell’s System 57 platform, primarily designed for industrial automation and safety monitoring. According to available specifications, this card functions as a specialized controller, likely a channel controller for gas detection, process monitoring, or automation signals, with applications across chemical, oil & gas, manufacturing, and hazardous environment industries.
The key technical features of the Honeywell 05701-A-0293 include voltage input compatibility ranging from 85-265V AC with a frequency of 50/60Hz, and current sensing capabilities of 0-5A AC with a high accuracy of ±0.3%. It is equipped with dual relay outputs rated at 5A, 250V AC, making it suitable for switching control and alarm signaling. The device supports Ethernet/IP communication protocol, simplifying integration into larger control systems for remote monitoring and diagnostics. Its operating temperature range extends from -25°C to +60°C, ensuring reliable operation under typical industrial environmental conditions
This control card is often paired with Honeywell’s power supplies such as 05701-A-0405 and 05701-A-0406, and interfaces with sensor modules, relay cards, and system racks to provide comprehensive system functionality alongside other cards like control modules, sensor drivers, and interface units. The 05701-A-0293 provides a critical role in signal acquisition, control logic execution, and system safety features, making it an essential element in automated safety systems and process control setups.
The technical specification overview in the table below summarizes its fundamental parameters:
| Parameter | Value |
|---|---|
| Model | Honeywell 05701-A-0293 |
| Brand | Honeywell |
| Product Type | Automation Control Card |
| Voltage Input | 85-265V AC, 50/60Hz |
| Current Sensing | 0-5A AC, ±0.3% accuracy |
| Relay Output | 2x SPDT, 5A @ 250V AC |
| Communication Protocol | Ethernet/IP |
| Operating Temperature | -25°C to +60°C |
| Dimensions | Approximate size for rack mounting |
| Weight | About 0.5 kg |
- 05701-A-0293
Related modules within the Honeywell System 57 environment include 05701-A-0301 (single channel control card for 4-20mA signals), 05701-A-0302 (catalytic sensor control card), 05701-A-0351 (single-channel control card), and power supply units like 05701-A-0405 and 05701-A-0406. These modules work together to configure complete gas detection and process safety systems tailored to industrial needs.
Installation considerations include proper wiring, ensuring ambient temperature limits are maintained, and verifying that communication interfaces are correctly configured for network integration. Routine maintenance involves visual inspection of connection points, firmware updates, and system diagnostics to ensure signal accuracy and system safety.
