Product Model: IC694ALG542
Product Brand: GE Fanuc
Product Series: PACSystems RX3i
Product Features:
• High-resolution multi-range analog input capability
• Wide compatibility with RX3i control systems
• Stable signal acquisition for voltage and current devices
• Strong electrical isolation and noise resistance for industrial use
Technical Specifications
| Specification | Value |
|---|---|
| Product Model | IC694ALG542 |
| Brand | GE Fanuc |
| Series | PACSystems RX3i |
| Channels | 4 analog inputs |
| Input Types | Voltage and current |
| Supported Ranges | Common 4–20 mA, 0–20 mA, 0–10 V |
| Input Resolution | High-resolution A/D conversion |
| Input Isolation | Channel-to-backplane and channel-to-channel isolation |
| Backplane Current Draw | Approx. 130 mA at 5 VDC |
| Operating Temperature | 0–60°C typical |
| Module Width | Standard RX3i slot |
| Diagnostics | Channel status and fault detection |
- IC694ALG542
- IC694ALG542
Related Models
• IC694ALG391 – Voltage-only input module with expanded ranges
• IC694ALG220 – Current-only input unit for loop-powered transmitters
• IC694ALG708 – High-density analog input module for larger systems
• IC694ALG432 – Thermocouple input module for temperature measurement
• IC694ALG442 – RTD input module for precision temperature sensing
• IC693ALG392 – Legacy analog module for Series 90-30 systems
