Key Technical Specifications
| Parameter | Value |
|---|---|
| System Compatibility | Foxboro I/A Series FBM242 Discrete Output Module |
| Termination Type | 2-Tier Compression Terminal Assembly |
| Output Rating | 5A Relay Out support |
| Conductor Capacity | Accepts standard multi-strand or solid industrial field wiring |
| Enclosure Integration | Standard 200 Series baseplate mount configuration |
| Operating Temperature | -20 to +70 °C |
| Insulation Resistance | High-dielectric industrial grade housing |
| Mounting Type | DIN-rail / baseplate interlock mechanism |
| Material Construction | Flame-retardant industrial thermoplastic |
| Weight | ~0.8 kg |
Product Introduction & Supply Chain Strategy
The Foxboro P0916NG is a 2-tier compression termination assembly engineered to interface field wiring with the FBM242 discrete output module in Foxboro I/A Series Distributed Control Systems. It secures heavy-duty relay connections and maintains reliable signal routing across complex industrial control loops.
Securing this termination block as a certified New Surplus part prevents unexpected connection failures caused by degraded terminal blocks or oxidized contacts. Sourcing uninstalled factory surplus protects Total Cost of Ownership (TCO) without risking plant reliability on second-hand hardware.
Installation & Configuration Guide
1
Pre-Installation (Prep & Safety)
Prerequisite
1.Pre-Installation (Prep & Safety):Prerequisite.
Isolate power to the FBM242 baseplate and apply strict lock-out/tag-out (LOTO) protocols. Ground yourself with an ESD wrist strap. Document field wire tagging maps before loosening any terminal screws.
Verification: Confirm zero voltage across baseplate terminal connections using a calibrated multimeter.
2
Removal
Mechanical Extraction
2.Removal:Mechanical Extraction.
Label each individual field wire clearly to ensure proper phase alignment. Open the terminal block housing covers, loosen the compression screw fasteners, and extract conductors carefully from the legacy P0916NG assembly.
Verification: Inspect extracted wire ends for oxidation or fraying, trimming back to clean copper if necessary before reconnection.
3
Installation (Clone & Seat)
Hardware Setup
3.Installation (Clone & Seat):Hardware Setup.
Mount the new Foxboro P0916NG termination assembly securely onto the baseplate interface. Insert each field conductor into its corresponding 2-tier compression slot and torque screw fasteners to manufacturer specifications.
Verification: Perform a gentle pull test on each terminated conductor to verify tight mechanical seating and secure electrical contact.
4
Power-On & Testing
Commissioning
4.Power-On & Testing:Commissioning.
Restore baseplate power and verify loop continuity. Run diagnostic checks from the engineering station to confirm discrete output commands actuate field relays correctly without intermittent open-circuit faults.
Verification: Verify that control system registers show stable status feedback across all 16 discrete output channels.
P0916NG
P0916NG
Firmware/Software Versions & Upgrade Notes
- Hardware Revision Baseline: Ensure the physical pin header configuration matches the FBM242 module interface design.
- Compatibility Warnings: Do not mix terminal assembly variants across different FBM types (e.g., matching an analog termination block to a discrete output module), as pin configurations will cause short circuits or signal routing errors.
- Maintenance Best Practice: Inspect compression screw torque periodically during scheduled outages to prevent loose connections caused by thermal expansion and mechanical vibration.
Frequently Asked Questions (FAQ)
- Why is this Foxboro P0916NG assembly classified as New Surplus?
This unit is an authentic, original OEM-manufactured product procured from verified surplus channels after inventory rationalizations. It has never been installed, wired, or exposed to industrial field environments.
- How can I verify this termination block is not refurbished or used?
We enforce a strict zero-tolerance policy against second-hand parts. Each unit features pristine screw threads, unblemished plastic housing, and factory-fresh contact pins.
- What are the hidden risks of using degraded termination blocks?
Aged terminal blocks often suffer from micro-corrosion, cracked plastic housings, and loose spring contacts, causing intermittent relay dropouts, erratic signal behavior, and unexpected process faults.
- Is the P0916NG compatible with all FBM modules?
No, it is specifically designed for the FBM242 discrete output module requiring 5A relay out compression termination.
- What warranty terms apply to this unit?
This product is backed by a comprehensive 1-year replacement warranty, matching standard OEM reliability benchmarks and protecting your facility’s operational investment.
