The Honeywell EG1033AC01 is an ultraviolet (UV) flame amplifier specifically designed for industrial gas turbine flame monitoring systems. Primarily used in power generation facilities, pumping stations, and shipboard power generation, this module detects UV radiation emitted by hydrocarbon flames to safeguard turbine operations by signaling flame presence or absence with high reliability. The EG1033AC01 amplifier supports infrared (IR) and UV flame sensors like the Honeywell LG1093 series, providing superior flameout protection essential for preventing turbine damage and ensuring uninterrupted industrial power generation.
This amplifier is designed to operate under harsh industrial conditions, with an operating temperature range from -40 to +176 °C (-40 to 349 °F) and DIN rail mounting for straightforward installation. It supports power inputs of 20-35 VDC with a maximum consumption of 10 watts and features relay contact outputs for flame detection signaling. The response time for flame detection is rapid, typically 0.1 seconds, and flame loss detection is no more than 0.2 seconds. The unit is robustly constructed with CE certification for electromagnetic compatibility (EMC) and low voltage directive (LVD), suitable for use in hazardous and demanding industrial environments.
- EG1033AC01
Key advantages of the Honeywell EG1033AC01 include high sensitivity to UV flames in the 1800-2600 angstrom range, making it “solar blind” and unaffected by thermal blackbody radiation. This ensures reliable flame monitoring even in the presence of strong ambient light or thermal noise. The amplifier can power and manage two independent sensors, enabling redundancy and increased system reliability. Its long mean time between failures (MTBF) of over 10,000 hours and compliance with Factory Mutual explosion-proof standards underscore its suitability for safety-critical applications.
| Parameter | Value |
|---|---|
| Model | EG1033AC01 |
| Brand | Honeywell |
| Product Type | UV Flame Amplifier |
| Power Input | 20-35 VDC, max 10 Watts |
| Output | Relay contacts (flame/no flame) |
| Flame Detection Time | Typical 0.1 seconds, max 1.0 sec |
| Flame Loss Detect Time | Max 0.2 seconds |
| Operating Temperature | -40 to +176 °C (-40 to 349 °F) |
| Mounting | DIN Rail |
| Sensor Compatibility | UV Flame sensors (LG1093 series) |
| Certifications | CE, Factory Mutual Explosion Proof |
| Dimensions | 6.62 x 4.25 x 4.44 inches |
| Weight | Approximately 0.8 kg |
Installation requires attention to power supply quality and proper grounding, with LED indicators aiding in status monitoring and troubleshooting. The amplifier’s design supports reliable flame monitoring in industrial environments with high vibration, temperature extremes, and electrical noise. Maintenance typically involves periodic functional testing and inspection to ensure optimal performance.
