Key Technical Specifications
| Parameter | Value |
| Model Number | 472556R1 |
| Alternative Name | SELEMA |
| Input Voltage | 24 V DC (nominal) |
| Logic Voltage Output | Multiple regulated rails (+5V, +/- 15V typical) |
| Mounting Type | Component Level / Chassis Mount |
| Protection | Integrated overcurrent and surge suppression |
| Operating Temp | 0 to +55 °C |
| Storage Temp | −40 to +85 °C |
| Weight | 0.85 kg (approx. 1.87 lbs) |
| Dimensions | 233 mm x 160 mm x 35 mm |
Product Introduction
The ABB 472556R1, commonly identified by the SELEMA marking, is a critical power supply and interface board primarily used within ABB’s legacy industrial drive and DCS ecosystems. It serves as the electrical backbone for control electronics, converting raw plant power into the stabilized, low-noise voltages required by sensitive microprocessor-based logic.
Engineers specify the 472556R1 because of its high MTBF (Mean Time Between Failures) and precision voltage regulation. Unlike generic alternatives, this module is engineered to withstand the harmonic distortion and thermal fluctuations typical of heavy industrial motor control centers. It is a drop-in replacement that ensures your drive system remains within original OEM performance specifications.
- 472556R1
- 472556R1
Installation & Configuration Guide
Stage 1: Pre-Installation Preparation (Estimated Time: 10 mins)
- ⚠️ Safety First: Isolate the main drive power. Lock out/tag out the primary breaker. Wait at least 5 minutes for the DC bus capacitors to discharge to safe levels (<50V).
- Tools Required: ESD wrist strap, Phillips PH1/PH2 screwdrivers, and a Fluke 115 (or equivalent) multimeter.
- Data Backup: While this is a power/interface board, verify any associated CPU modules have their latest parameters saved to non-volatile memory or an external PC.
Stage 2: Removing the Old Module (Estimated Time: 5 mins)
- Attach your ESD strap to a grounded point on the cabinet frame.
- Disconnect all ribbon cables and terminal headers. Label every cable clearly; many ABB cables look identical but carry different signals.
- Unscrew the mounting standoffs.
- Pull the board straight out. Avoid any twisting motion that could stress the PCB or snap a solder joint on the backplane connectors.
Stage 3: Installing the New Module (Estimated Time: 10 mins)
- Compare the new 472556R1 against the old unit. Check the revision number (e.g., R1 vs R2). Usually, these are backward compatible, but verify jumper settings.
- Configuration Clone: Replicate all jumper positions (J1, J2, etc.) exactly from the old board. I’ve seen techs spend hours chasing “phantom” faults because a single jumper was set to internal vs. external 24V.
- Mount the board and tighten the screws to approximately 0.8 Nm.
- Reconnect all cables, ensuring they “click” into place.
Stage 4: Power-On & Testing (Estimated Time: 5 mins)
- Pre-Power Check: [ ] All cables seated. [ ] No loose screws/washers in the rack. [ ] 24V supply isn’t shorted to ground.
- Power-On: Apply control power first (keep the 480V/main bus isolated if possible).
- Verification: Check status LEDs. A steady green indicates the internal rails are within tolerance. Use your multimeter to verify the 24V input at the terminal block.
- ⚠️ Troubleshooting Note: If the board smells hot or LEDs fail to light, kill power immediately. Check for a reversed ribbon cable or a short in the field wiring.
Frequently Asked Questions (FAQ)
Q: Can I hot-swap the 472556R1 while the drive is energized?
A: Absolutely not. Swapping this board under power will almost certainly cause an arc at the connector pins and likely fry the logic on the receiving end. Always kill the control power and wait for the DC bus to bleed down.
Q: This module is marked as “SELEMA.” Is it different from the standard ABB 472556R1?
A: They are the same part. SELEMA is often the sub-manufacturer for these specific ABB boards. As long as the part number 472556R1 matches, it is the correct replacement for your system.
Q: Why is your price lower than the OEM factory list?
A: We specialize in “New Surplus” stock. This means the parts are genuine and unused, often coming from cancelled projects or plant liquidations. We pass that savings on, and unlike the OEM, we actually have these sitting on the shelf ready to ship today.
Q: Will I need to reload the drive parameters after replacing this board?
A: Typically, no. The 472556R1 handles power and signal conditioning, not logic storage. However, if the power failure that killed the old board also corrupted the RAM on the main controller, a reload might be necessary. It’s always best practice to have your .dcf or .pcb files ready.
Q: Is there a newer replacement for this obsolete module?
A: ABB has migrated newer systems to the ACS880 series, but that requires a full cabinet retrofit. For keeping your existing DCS or high-power drive running, there is no direct “modern” equivalent that fits this form factor. Stick with the 472556R1 to avoid massive engineering costs.
