ABB 101935-217 Trigger Lamp Assembly Smart Color Flash Pack

Description

Key Technical Specifications

Product Introduction & Supply Chain Strategy

The ABB 101935-217 Trigger Lamp Assembly is an essential electro-optical component used in ABB Quality Control Systems (QCS) for paper, film, and continuous web monitoring lines. Designed to deliver precise, synchronized light flashes to measurement sensors, it enables continuous, real-time quality scanning across fast-moving production lines.

Securing this part as New Surplus provides a massive advantage for plant reliability. Refurbished flash and trigger assemblies carry a high risk of premature capacitor breakdown or micro-flicker, leading to inaccurate sensor readings, false process alarms, or complete line shutdowns. Sourcing genuine New Surplus inventory eliminates these failure vectors while providing significant savings compared to direct OEM list prices.

Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

1. Enforce strict Lock-Out/Tag-Out (LOTO) procedures on the scanner head and system power distribution.
2. Put on a grounded ESD wrist strap before handling the replacement module.
3. Document terminal wiring layouts and photograph existing mounting hardware and DIP switch configurations (if applicable) on the active unit.

Stage 2: Removal

1. Disconnect high-voltage and signal harness connectors carefully without applying tension to internal wiring.
2. Unbolt retaining fasteners holding the assembly in the optical sensor chassis.
3. Slide out the old module, ensuring backplane mounting pins are clear.

Stage 3: Installation (Clone & Seat)

1. Unpack the New Surplus ABB 101935-217 inside an ESD-protected area.
2. Align the mounting tabs and insert the module smoothly into position.
3. Torquing fasteners to spec (1.2–1.5 Nm) to prevent mechanical vibration issues during scanner movement.
4. Reattach signal and high-voltage harnesses.

Stage 4: Power-On & Testing

1. Measure system power supply outputs to verify voltage rails meet the specified operating parameters.
2. Energize system power and perform a self-test diagnostic via the main ABB QCS operator workstation.
3. Verify synchronized flash operation and inspect real-time sensor signals to confirm proper illumination stability.

101935-217

101935-217

Firmware/Software Versions & Upgrade Notes

• System Compatibility: Compatible with standard ABB QCS Smart Color measurement platforms.
• Revision Matching: Ensure system optical control software aligns with the revision code printed on the 101935-217 label.
• Upgrade Guidance: Hardware replacements rarely require firmware updates; however, replacing an older revision with a newer board revision may require updating sensor calibration tables within the host controller. Avoid upgrading software or controller firmware during an emergency swap to isolate physical installation variables.

Frequently Asked Questions (FAQ)

Q: Is this ABB 101935-217 unit genuine original or refurbished?

A: This product is 100% Brand New Surplus. It is an original OEM module that has never seen operational use, was never pulled from a decommissioned plant, and has zero refurbished components. It is stored in anti-static protective packaging and verified by quality control before shipment.

Q: Why choose New Surplus over a refurbished unit?

A: Trigger assemblies rely on high-energy storage elements and flash components that degrade with thermal cycles and age. Refurbished parts often contain aged capacitors that pass simple bench tests but fail under continuous field loads, leading to unplanned downtime. New Surplus guarantees original manufacturing standards and a full operational lifespan.

Q: What is the lead time and availability for this part?

A: We maintain this item in stock to support emergency replacements. Standard shipments dispatch within 24 hours from warehouse stock, with expedited same-day shipping options available for critical outage situations.

Q: What warranty coverage applies to this module?

A: Every ABB 101935-217 New Surplus unit includes a full 1-Year Comprehensive Warranty covering functional operation, matching or exceeding standard factory terms for spare parts.

Q: Can this unit be hot-swapped while the scanner head is running?

A: No. Always disconnect primary power and ensure high-voltage supply circuits are fully discharged before removing or inserting the assembly to prevent arc flashing or damaging sensitive optical sensors.
