3. Key Technical Specifications
- Number of Channels: 8
- Output Type: 4-20 mA (configurable ranges)
- Isolation: Galvanic isolation per channel or group
- Resolution: 12-14 bits typical for series
- Load Capability: Up to 750 Ω typical
- Update Time: Fast scan cycle integration with controller
- Diagnostics: Output monitoring, open circuit detection
- Power Consumption: Low module bus draw
- Operating Temperature: 0 to +55 °C
- Mounting: Compatible S800 termination units
- Rated Insulation: Standard for S800 series
4. Product Introduction
The ABB AO810V2 is an 8-channel analog output module in the S800 I/O family. It drives 4-20 mA signals to final control elements such as valves, positioners, and variable speed drives in process automation systems.
Maintenance teams and integrators rely on it for reliable, isolated outputs that integrate directly with AC 800M and 800xA controllers. Each channel provides accurate current control with built-in diagnostics to minimize undetected failures.
- AO810V2 3BSE038415R1
- AO810V2 3BSE038415R1
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No output current | Module power or config issue | ❌ Low | Measure loop voltage and check controller output value | Verify 24 V supply and module parameters |
| Output stuck or incorrect value | Wiring fault or load problem | ✅ High | Measure current at module terminals with multimeter | Check field wiring and load resistance |
| Open circuit diagnostic | Broken loop or high resistance | ✅ High | Test continuity from module to device | Inspect terminals and field cabling |
| Erratic or noisy output | Grounding or EMI | ✅ Medium | Check shield grounding and cable routing | Ensure proper single-point grounding |
| Module error LED | Internal fault or bus issue | ✅ High | Review controller diagnostics | Cycle power; replace if persistent |
Provide diagnostic logs, photos, and loop details when contacting support.
6. Frequently Asked Questions (FAQ)
Is the AO810V2 hot-swappable? No. Shut down the appropriate rack power or use redundant configurations where available. Hot insertion risks damage to the backplane or outputs.
What is the condition of these modules? New Original / New Surplus. Every unit receives full inbound inspection, functional load testing on a live S800 rack, and documentation of output accuracy across the range.
Will this replace an older AO810? Yes, the V2 is the current version with improved characteristics. Confirm compatibility with your termination unit and controller firmware.
How do I handle HART communication? Some configurations support HART pass-through. Verify your specific setup and controller capability. Standard AO810V2 focuses on reliable 4-20 mA output.
What precautions for field wiring? Use shielded twisted pair. Respect polarity and keep total loop resistance within limits (typically <750 Ω). Proper grounding prevents noise and ground loops.
What warranty and support do you offer? 1-year warranty on functionality. Test report included showing channel accuracy under load. Photos and test videos available. Fast shipping from stock.
