Alcatel-Lucent PHP200B 849068119 E5I2TPPAAA AC Power Supply

Description

Key Technical Specifications

Product Introduction & Supply Chain Strategy

The Alcatel-Lucent PHP200B (849068119) is the primary AC power interface for the 1830 Photonic Service Switch series, specifically optimized for smaller footprint shelves like the PSS-4. This module converts standard 110V/220V AC input into the stable DC rails required by sensitive transponders and optical line cards. Featuring built-in over-voltage and over-current protection, the PHP200B ensures that power spikes do not reach the expensive switching fabric of the PSS chassis.

From a Supply Chain perspective, power supplies are “Consumable Criticals”—they are the most likely components to fail during electrical storms or utility instability. Sourcing the PHP200B as New Surplus is a high-impact ROI decision. While refurbished power supplies often have dried-out electrolytic capacitors that lead to “silent” voltage ripples and intermittent card reboots, our New Surplus units offer the full factory-rated MTBF (Mean Time Between Failures). Keeping at least one PHP200B in your on-site buffer stock reduces your recovery time from hours to minutes, effectively acting as a low-cost insurance policy for your optical backbone.

PHP200B 849068119

Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

• Verify Load: Ensure the total power draw of the cards in the PSS shelf does not exceed the 200W rating of a single PSU if you are running in a non-redundant configuration.
• Visual Check: Inspect the 849068119 connector pins for any signs of transit damage or debris.
• Safety: Ensure the AC power cord is disconnected before sliding the module into the chassis.

Stage 2: Removal (If Replacing)

• Redundancy Check: If the shelf has two PSUs, verify the second unit is healthy (Green “Power” LED) before removing the faulty one.
• Unplug: Disconnect the AC power cable from the rear/front of the PHP200B unit.
• Extraction: Loosen the thumb screws and pull the module straight out using the integrated handle.

Stage 3: Installation (Clone & Seat)

• Insertion: Align the PHP200B with the power slot guides. Slide it in firmly until you feel the connectors engage with the backplane.
• Locking: Tighten the thumb screws to ensure a secure mechanical fit and proper grounding.
• Cabling: Connect a high-quality, grounded AC power cord.

Stage 4: Power-On & Testing

• LED Status: Confirm the “PWR” or “OK” LED turns solid green. A red “FAIL” LED indicates an internal fault or input voltage issue.
• Management Audit: Log into the 1830 PSS management interface to verify that the PSU is recognized and that the power consumption is within normal operating limits.

Firmware/Software Versions & Upgrade Notes

The PHP200B is a hardware-level power converter and does not typically require independent firmware management. However, its presence and status monitoring are dependent on the Equipment Controller (EC) card software.

Strategic Note: If the 1830 PSS management system shows the PSU as “Unknown Equipment,” it may indicate that the shelf software version is older than the hardware revision of the PHP200B. Always ensure your PSS software load is compatible with E5I2TPPAAA hardware levels to maintain full remote telemetry and alarm reporting.

Frequently Asked Questions (FAQ)

• Can I mix the PHP200B with a DC power supply in the same shelf?

  No. The 1830 PSS chassis typically requires uniform power types (either all AC or all DC) to ensure proper backplane distribution and grounding.

• Why buy New Surplus instead of used for a power supply?

  Power supplies are high-heat environments. Used units have significantly aged capacitors and fans. New Surplus gives you the reliability of a brand-new component without the OEM “new” price tag.

• Is this compatible with the PSS-32?

  The PHP200B is generally intended for the smaller PSS-4 or PSS-16 shelves. Larger PSS-32 shelves usually require higher-wattage DC power systems. Always check your site engineering plan.

• Does it come with an AC power cord?

  Typically, the PSU is sold as the module only. If you require a specific regional AC cord (NEMA 5-15P for US or CEE 7/7 for EU), please specify at the time of order.

• What is the warranty?

  We provide a 1-year replacement warranty. If the unit fails to provide stable power or fails POST upon installation, we will provide a replacement unit immediately.
