1756-L1M1
1756-L1M1
1756-L1M1

Allen-Bradley 1756-L1M1 ControlLogix Processor Module

  • Model: 1756-L1M1
  • Brand: Allen-Bradley (Rockwell Automation)
  • Series: ControlLogix 5550
  • Core Function: Execute PLC control logic and communications
  • Product Type: Processor (CPU) Module
  • Key Specs: 512 KB user memory, RS-232 serial port, battery-backed memory
  • ⚠️ Obsolete Model – Limited Stock Available
  • Condition: New Original / New Surplus or Refurbished (Tested)
Get a Quote
Categories: , , , , SKU: 1756-L1M1 Brand:

Description

Key Technical Specifications

Parameter Value
Product Type Processor (CPU) Module
Manufacturer Allen-Bradley / Rockwell Automation
Model Number 1756-L1M1
Product Series ControlLogix 5550
User Memory 512 KB
Programming Software RSLogix 5000 Version 8.02 or later
Communication Port One RS-232 serial port
Nonvolatile Memory Battery-backed memory
Replacement Battery 1756-BA1 Lithium Battery
Isolation Voltage 30 V continuous
Backplane Current 0.95 A @ 5 V DC, 0.02 A @ 24 V DC
Average Power Dissipation 4.6 W
Operating Temperature 0 to 60 °C
Storage Temperature −40 to 85 °C
Relative Humidity 5–95% non-condensing
Enclosure Rating Open Type

The 1756-L1M1 is a legacy ControlLogix 5550 controller providing 512 KB of user memory for machine and process control applications. It supports RSLogix 5000 programming and uses battery-backed memory retention.



Product Introduction

The Allen-Bradley 1756-L1M1 is a ControlLogix 5550 processor module that executes ladder logic, function block, structured text, and sequential function chart programs within a ControlLogix chassis. It served as a primary controller for manufacturing, process automation, material handling, and utility systems before the introduction of newer Logix families.

Although now considered a legacy controller, many facilities continue operating 1756-L1M1 processors because validated production systems often remain unchanged for years. When maintaining these installations, matching firmware revisions, battery condition, and project backups is considerably more important than simply replacing the hardware.

1756-L1M1
1756-L1M1
1756-L1M1
1756-L1M1



Installation & Configuration Guide

Stage 1 – Pre-Installation Preparation (Estimated Time: 15 Minutes)

⚠️ Safety First

  1. Notify production personnel of scheduled downtime.
  2. Place the machine or process in a safe operating state.
  3. Apply lockout/tagout procedures.
  4. Remove chassis power.
  5. Wait at least 5 minutes before removing the controller.

Tools Required

  • Grounded ESD wrist strap
  • PH1 screwdriver
  • Fluke 115 digital multimeter
  • Laptop with RSLogix 5000
  • 1756-CP3 serial programming cable
  • Smartphone for documentation

Data Backup

  1. Upload the complete controller project.
  2. Record firmware revision.
  3. Save communication settings.
  4. Photograph chassis slot locations.
  5. Verify battery condition.

Stage 2 – Removing the Old Controller (Estimated Time: 10 Minutes)

  1. Verify chassis power is OFF.
  2. Disconnect the serial programming cable.
  3. Label all communication cables.
  4. Release the locking tabs.
  5. Remove the processor straight from the chassis.
  6. Inspect the backplane connector.

⚠️ Do not discard the original processor until the replacement has successfully entered RUN mode.

Stage 3 – Installing the New Controller (Estimated Time: 20 Minutes)

  1. Wear a grounded ESD wrist strap.
  2. Verify the replacement catalog number is 1756-.
  3. Install the controller into the same chassis slot.
  4. Install or verify the 1756-BA1 battery.
  5. Connect the programming cable.
  6. Confirm firmware compatibility.
  7. Download the backed-up project if required.

Self-Checklist

  • Correct controller model
  • Battery installed
  • Firmware verified
  • Project backup available
  • Controller fully seated

Stage 4 – Power-On & Testing (Estimated Time: 20 Minutes)

Pre-Power Checks

  • Verify chassis power supply voltage.
  • Confirm backplane connector integrity.
  • Verify battery installation.
  • Inspect communication cables.

Commissioning Steps

  1. Apply chassis power.
  2. Observe the OK, RUN, and FORCE LEDs.
  3. Connect using RSLogix 5000.
  4. Verify firmware revision.
  5. Confirm controller identity.
  6. Download the project if necessary.
  7. Test all critical I/O before returning equipment to service.

⚠️ Troubleshooting Notes

  • Solid Fault LED: Verify firmware compatibility with the project.
  • Unable to communicate: Check serial cable configuration and communication parameters.
  • Controller enters Fault Mode: Review the fault code before cycling power.
  • Battery warning: Replace the 1756-BA1 battery before placing the controller into long-term service.

Common Field Pitfalls

❗ Firmware Revision Mismatch

One of the most common causes of extended downtime is downloading a project developed for a different firmware revision. Always identify the controller firmware before removing the original CPU.

❗ Battery Replacement

The 1756- relies on a lithium battery to maintain memory. I’ve seen controllers arrive in excellent physical condition only to lose retained data because the battery had exceeded its service life. Replace aging batteries during scheduled maintenance instead of waiting for a low-battery alarm.

❗ Chassis Slot Assignment

The replacement controller must be installed in the correct slot. An incorrect slot assignment can prevent the project from communicating with local I/O modules.

❗ Legacy Software Compatibility

Older controllers frequently require matching RSLogix 5000 versions. Installing the latest programming software does not guarantee compatibility with legacy firmware.

❗ Electrostatic Discharge

Processor modules contain high-density electronic components that are susceptible to ESD damage. Always use a grounded wrist strap and ESD-safe work surface.

Keep these checks in mind and you’ll eliminate most processor replacement problems before production resumes.



Frequently Asked Questions (FAQ)

Q1. Is the 1756- still manufactured?

No.

The is a legacy ControlLogix 5550 controller. Most units available today are New Surplus inventory or professionally tested refurbished controllers. Availability depends on remaining inventory.

Q2. Can I replace a 1756- with a newer Logix controller?

Yes, but it is not a direct hardware swap.

Migration to newer ControlLogix 5570 or 5580 controllers typically requires firmware validation, project conversion, and compatibility verification for communication modules and I/O. Review the entire system architecture before upgrading.

Q3. Will replacing the controller erase my PLC program?

Potentially.

If the project has not been backed up externally and the battery has failed, retained memory may already be lost. Before removing the controller, upload the complete project whenever communication is available.

Q4. Why is your price lower than OEM factory pricing?

Most available 1756- processors come from surplus industrial inventory, canceled expansion projects, or unused maintenance stock. Pricing reflects inventory source rather than product capability. Always request serial number verification, inspection records, and warranty information before purchase.

Q5. How is every 1756- tested before shipment?

Each controller should undergo a documented inspection process:

  1. Inbound Inspection & Traceability
    • Verify serial number and product label.
    • Inspect enclosure, connectors, and PCB.
    • Check for corrosion, repairs, scratches, and UV discoloration.
  2. Functional Testing
    • Install in a genuine ControlLogix chassis.
    • Verify power-on diagnostics.
    • Test serial communications.
    • Download and execute a sample RSLogix 5000 project.
    • Perform continuous operation for more than 24 hours while monitoring controller stability.
  3. Electrical Testing
    • Insulation resistance test using a 500 V Megger where applicable.
    • Verify power consumption and grounding continuity.
  4. Firmware Verification
    • Record firmware revision.
    • Verify memory operation.
    • Test battery-backed retention.
  5. Final QC & Packaging
    • QC approval.
    • Anti-static ESD packaging.
    • Heavy-duty shipping carton.
    • QC Passed label with inspection date.

Test photographs and operational videos should be available upon request.

Q6. Which battery does the 1756- use?

The controller uses the 1756-BA1 lithium battery to retain memory when chassis power is removed. Replace the battery only with the recommended part number and follow Rockwell’s battery replacement procedure.

Q7. What should I verify before installing a replacement 1756-?

Before commissioning, verify:

  • Exact catalog number ()
  • Firmware revision
  • RSLogix 5000 software version
  • Controller project backup
  • Battery condition
  • Chassis slot location
  • Communication settings
  • Backplane power capacity

From practical field experience, most startup delays after replacing a legacy ControlLogix processor are caused by firmware mismatches, missing project backups, or depleted backup batteries—not by defective hardware. Careful preparation before removing the original controller usually prevents hours of unnecessary recovery work.
