3. Key Technical Specifications
- Length: 8.0 meters (26.2 feet)
- Cable Type: 3300 XL Standard Extension
- Connectors: Miniature ClickLoc coaxial
- Capacitance: 69.9 pF/m typical
- Temperature Rating: Up to 177°C (350°F) continuous
- Armor Option: Per configuration (00-05)
- Compatibility: 3300 XL 8 mm probes and Proximitor sensors
- Total System Length: Must match Proximitor (5 m, 9 m systems) when combined with probe
- Mounting/Installation: Inline between probe and Proximitor
- Approvals: Standard industrial certifications
4. Product Introduction
The Bently Nevada 330130-080-00-05 is a 3300 XL standard extension cable, 8.0 meters long, designed to connect 8 mm proximity probes to the Proximitor sensor in machinery monitoring systems.
It maintains signal integrity over distance while providing robust mechanical protection. Use this cable to achieve the correct total length for your 5 m or 9 m transducer system. In field installations, the ClickLoc connectors and armor options reduce installation time and improve long-term reliability on turbines and compressors.
- 330130-080-00-05
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No gap voltage | Cable disconnected or damaged | High | Check continuity between connectors | Inspect for pinches or cuts; reseat connectors |
| Noisy or erratic signal | Poor shielding or ground | High | Measure cable capacitance and resistance | Replace if out of spec; verify single-point ground |
| Intermittent connection | Loose ClickLoc connector | Medium | Tug test connectors gently | Fully seat until click is heard |
| High temperature failure | Exceeded cable rating | Low | Check local operating temp | Use high-temperature version if needed |
| Signal loss over length | Wrong total system length | Low | Verify probe + cable = Proximitor rating | Adjust cable length to match system |
Provide photos of installation, measured gap voltage, and cable markings if further help is required.
6. Frequently Asked Questions (FAQ)
What length is the 330130-080-00-05? 8.0 meters (26.2 feet). Always confirm total probe + extension equals your Proximitor sensor length.
Can I use this with any 3300 XL probe? Yes, with standard 3300 XL 8 mm probes. Match system lengths for proper calibration.
Is it armored? The -05 option typically includes connector protector or armor variant. Check exact suffix for your needs.
How do I connect it? Hand-tighten ClickLoc connectors until they click. Do not use tools that could damage the coaxial pins.
Is this New Surplus? New Original / New Surplus. Cables are factory sealed and tested.
What is the maximum temperature? Up to 177°C (350°F) for standard XL cables. Higher temperature versions are available for extreme applications.
What about warranty and stock? 1-year warranty. Extension cables like this are commonly stocked—confirm your exact length and options for availability.
