- Key Technical Specifications
| Parameter | Options / Value Code Breakdown | Parameter Value |
| Base Model | 330130 | 3300 XL Standard Extension Cable |
| Cable Length | -080 | 8.0 meters (26.2 feet) |
| Armor Option | -00 | Unarmored cable |
| Agency Approvals | -CN | China / CCC hazardous area approvals |
| System Impedance | — | 50 Ω nominal high-frequency coaxial impedance |
| Connector Type | — | Miniature coaxial ClickLoc male & female connectors |
| Capacitance | — | 69.9 pF/m (21.3 pF/ft) typical |
| Operating Temp Range | — | −51 to +177 °C (−60 to +350 °F) |
| Minimum Bend Radius | — | 25.4 mm (1.0 in) minimum static bend radius |
- Product Introduction & Supply Chain Strategy
The Bently Nevada 330130-080-00-CN is an 8.0-meter unarmored extension cable designed for the 3300 XL 8mm and 5mm Proximity Transducer Systems. It bridges the physical gap between a 1.0-meter proximity probe installed at the machine journal and a panel-mounted 3300 XL Proximitor sensor, completing the required 9.0-meter total system electrical length.
This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability. Refurbished extension cables carry severe risks of internal coaxial shielding degradation, moisture contamination inside the connectors, or altered cable capacitance, which directly cause false vibration trips or corrupted linear scale factor readings (200 mV/mil). Securing this cable as New Surplus guarantees full signal integrity, lowers total cost of ownership (TCO), and shields your facility from extended OEM lead times during critical turnaround windows.
330130-080-00-CN
330130-080-00-CN
- Installation & Configuration Guide
Stage 1: Pre-Installation (Prep & Safety)
- Verify that connected machinery protection channels are placed in bypass mode prior to disconnecting transducer cabling.
- Inspect the male and female ClickLoc connectors for dust, oil, or pin deformation.
- Ensure cable routing avoids sharp metal edges, high-voltage power conduits, and extreme hot surfaces above 177 °C (350 °F).
Stage 2: Removal
- Slide the connector protector sleeve away from the probe-to-cable junction.
- Disengage the ClickLoc coaxial connector by pulling straight back on the knurled locking collar.
- Disconnect the opposite end from the Proximitor sensor terminal or junction box and pull the cable from conduit runs.
Stage 3: Installation (Clone & Seat)
- Route the new 330130-080-00-CN cable through conduit or cable trays, adhering to the minimum 25.4 mm (1.0 in) bend radius.
- Push the male ClickLoc connector into the probe connector until you feel and hear the positive mechanical detent click.
- Slide the protective connector sleeve over the junction to seal out moisture and conductive contaminants.
- Connect the terminal end securely to the 3300 XL Proximitor sensor.
Stage 4: Power-On & Testing
- Measure the DC gap voltage at the Proximitor sensor output terminals using a calibrated digital multimeter (DMM).
- Verify that the static bias voltage matches target installation settings (typically −10.0 V DC for a centered 1.0 mm / 40 mil probe gap).
- Confirm that vibration and position readings on the 3500 rack display reflect stable baseline levels without signal spikes or intermittent noise.
- Firmware/Software Versions & Upgrade Notes
- System Compatibility: Compatible with all standard Bently Nevada 3300 XL 8mm and 5mm proximity transducers requiring a 9.0-meter total system length.
- Length Matching Rule: This cable is 8.0 meters in length. It MUST be paired with a 1.0-meter proximity probe to create a complete 9.0-meter system length. Mismatched cable lengths (e.g., pairing an 8.0m cable with a 0.5m probe) ruin system tuning, resulting in severe output voltage errors and uncalibrated scale factors.
- Hardware Architecture: The cable contains no active software or firmware. Accuracy depends entirely on exact physical capacitance, characteristic coaxial impedance, and clean electrical connections.
- Frequently Asked Questions (FAQ)
Q: Are these units really brand new, or are they refurbished/repaired cards?
A: This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules feature zero connector pin wear, pristine jacket insulation, intact gold plating, and original packaging opened only for mandatory QC inspection.
Q: Why is New Surplus priced higher than refurbished extension cables on the market?
A: Refurbished cables often suffer from micro-fractures in the internal shield from improper pulling or bending, creating intermittent resistance that triggers false high-vibration trips. Saving $75 on a used cable can cause a false trip on a multi-million-dollar compressor train. Our pricing reflects genuine, factory-fresh inventory that delivers full OEM signal integrity out of the box.
Q: What does the -CN option code represent on this part number?
A: The -CN suffix indicates China / CCC agency approvals for installation in regulated hazardous locations, ensuring compliance with local marine and industrial explosive atmosphere standards.
Q: Can I cut or splice this extension cable if it is too long for my junction box?
A: No. Never cut, splice, or shorten a proximity transducer cable. Altering the physical length changes total system capacitance and impedance, rendering the Proximitor calibration completely invalid. Excessive cable length should be neatly coiled and secured inside the junction enclosure.
Q: What warranty coverage applies to this module?
A: Every 330130-080-00-CN New Surplus cable comes backed by a comprehensive 1-year replacement warranty, fully verified through physical inspection, continuity/resistance checks, and ESD-safe packaging protocols.
