- Key Technical Specifications
| Parameter | Options / Value Code Breakdown | Parameter Value |
| Base Model | 3500/15 | 3500 Series Power Supply |
| Power Supply Type (Top) | -05 | High Voltage AC Supply (85 to 264 V AC) |
| Power Supply Type (Bottom) | -05 | High Voltage AC Supply (85 to 264 V AC) |
| Agency Approvals | -00 | Standard / Multiple Approvals (CSA, ATEX, IECEx) |
| Input Voltage Range | — | 85 to 264 V AC universal input |
| Input Frequency | — | 47 to 63 Hz |
| Output Capacity | — | 175 W continuous per supply module |
| Redundancy | — | Dual redundant configuration with automatic load sharing |
| Form Factor | — | Fits full left-hand power slot (Top and Bottom sub-slots) |
| Operating Temp Range | — | −30 to +65 °C (−22 to +149 °F) |
- Product Introduction & Supply Chain Strategy
The Bently Nevada 350015-05-05-00 is a dual-redundant High Voltage AC Power Supply combination designed for the 3500 Machinery Protection System. Configured with High Voltage AC supply modules in both top and bottom slots, it converts 85–264 V AC plant power into regulated DC voltages for all system rack modules, providing automated failover to ensure uninterrupted machinery protection.
This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability. Refurbished power supplies carry severe risks of degraded capacitors, dried thermal paste, or transformer coil fatigue, which can lead to unexpected rack shutdowns. Securing this full dual AC power supply set as New Surplus maintains 100% system uptime, lowers total cost of ownership (TCO), and shields your plant from extended manufacturer lead times.
- Installation & Configuration Guide
Stage 1: Pre-Installation (Prep & Safety)
High-Voltage Electrical Hazard
Disconnect and lock out incoming primary AC supply lines before connecting field wiring to the rear Power Input Module (PIM).
- Wear a grounded ESD wristband before handling power supply modules.
- Verify incoming line voltage matches the 85 to 264 V AC input requirement for the -05 option.
- Photograph and document existing line, neutral, and ground connections on the rear PIM terminal block.
Stage 2: Removal
- Open incoming AC line breakers supplying both top and bottom power feeds.
- Loosen captive screws on the front panel of the power modules and pull extraction handles straight out.
- Disconnect wiring from the rear PIM and loosen retaining screws to slide the PIM out of the rack chassis.
Stage 3: Installation (Clone & Seat)
- Insert the new Power Input Module (PIM) into the rear left slot and tighten retaining screws.
- Slide the top and bottom 3500/15 power supply modules into the front chassis guide rails until fully seated into the backplane.
- Hand-tighten all front captive thumbscrews to secure against vibration.
- Reconnect AC power lines (Line, Neutral, Earth Ground) to the designated PIM terminal blocks.
Stage 4: Power-On & Testing
- Energize the primary AC power feeds.
- Verify that the front panel SUPPLY OK green LEDs illuminate steadily on both top and bottom modules.
- Access 3500 Rack Configuration Software to confirm backplane bus voltages fall within nominal tolerances and no power supply faults are flagged.
- Firmware/Software Versions & Upgrade Notes
- Hardware Architecture: The 350015-05-05-00 is an analog power conversion system and contains no microprocessor firmware, microcontrollers, or DIP switch settings.
- Option Code Matching: The -05-05 suffix designates dual High Voltage AC modules. High Voltage AC supply modules MUST be paired with a High Voltage AC Power Input Module (PIM). Attempting to use a Low Voltage DC PIM (-01 or -02) with High Voltage AC modules will cause equipment damage.
- Hot-Swap Protection: In a dual-redundant configuration, either power module can be replaced while energized without interrupting rack operations, provided the remaining supply module is fully operational.
3500/15 350015-05-05-00
3500/15 350015-05-05-00
- Frequently Asked Questions (FAQ)
Q: Are these units really brand new, or are they refurbished/repaired cards?
A: This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules feature zero backplane pin wear, pristine internal components, zero thermal discoloration, and original packaging opened only for mandatory QC inspection.
Q: Why is New Surplus priced higher than refurbished power supplies on the market?
A: Refurbished power supplies often contain aged electrolytic capacitors near the end of their operational lifespan. Saving $200 on a used power module can cause an unexpected power loss across an entire 15-channel protection system. Our pricing reflects genuine, factory-fresh inventory that delivers a 10–15 year operational lifespan and zero failure risk out of the box.
Q: Does the 350015-05-05-00 include both front power supply modules and the rear PIM?
A: Yes. The complete 350015-05-05-00 assembly includes both the top and bottom High Voltage AC front supply modules as well as the matching High Voltage AC Power Input Module (PIM) for rear panel termination.
Q: What happens if one of the two power supply modules fails during operation?
A: Because both top and bottom slots contain active High Voltage AC modules (-05-05), the remaining operational module automatically supports 100% of the rack’s power demand with zero interruption to active vibration monitoring.
Q: What warranty coverage applies to this module?
A: Every 350015-05-05-00 New Surplus power supply set comes backed by a comprehensive 1-year replacement warranty, fully verified through high-potential voltage testing, load-step checks, and ESD-safe packaging protocols.
