3. Key Technical Specifications
- Module Type: Transient Data Interface (TDI)
- Communication Ports: Ethernet and serial for software connection
- Function: Primary gateway between 3500 rack and monitoring software
- Compatibility: Works with 3500 monitors for transient data capture
- Status Indicators: Front panel LEDs for module health and communications
- I/O Module: Paired with associated TDI I/O module
- Operating Temperature: -30°C to +65°C
- Power: Backplane powered from 3500 rack supplies
- Data Handling: Supports transient waveform and static data transfer
- Rack Slot: Standard full-height position in 3500 rack
4. Product Introduction
The Bently Nevada 350022-01-01-00 is the 3500/22 Transient Data Interface module. It connects the 3500 Machinery Protection System rack to Bently Nevada System 1 software and the 3500 configuration utility. It collects and passes both static and transient vibration data.
This TDI replaces older RIM modules in many upgrades. It provides the real-time link engineers rely on for continuous monitoring and diagnostics in critical machinery applications.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No connection to System 1 | Network or port issue | ✅ High | Verify Ethernet cable and IP settings | Ping module from configuration PC |
| TDI LEDs show fault | Module or backplane problem | ✅ High | Check front panel status LEDs | Cycle power or reseat module |
| Missing transient data | Configuration mismatch | ✅ Medium | Review software setup for rack | Reload configuration file |
| Intermittent comms | Cable or switch problem | ❌ Medium | Test with direct connection | Replace Ethernet cable |
| Software timeout errors | Firmware version conflict | ✅ Medium | Check TDI firmware vs software | Update to compatible versions |
Capture screenshots of software errors and LED states when you reach out for help.
- 3500/22 350022-01-01-00
- 3500/22 350022-01-01-00
6. Frequently Asked Questions (FAQ)
What is the main job of the 350022-01-01-00 TDI? It acts as the communication bridge between the 3500 rack and your monitoring computers. Without it, you lose access to configuration and live data viewing.
Can I upgrade from an older 3500/20 RIM to this TDI? Yes in most cases, but check compatibility of your monitor modules first. Some older M-series monitors may need updates.
Is the TDI hot-swappable? In systems with redundant TDI setups it is possible. Single TDI racks require a brief shutdown. Plan the swap during a maintenance window.
What software does it work with? It supports Bently Nevada System 1 Condition Monitoring software and the 3500 System Configuration Software. Confirm your versions match the TDI firmware.
How long until I can get one? We stock popular TDI configurations and ship quickly. Let us know your urgency for this 350022-01-01-00.
Do I need the separate I/O module? Yes. The 350022 main module pairs with a TDI I/O module for full rear connections. We can supply the complete assembly.
What testing do you do on these interface modules? We power them up in a test rack, verify Ethernet communications, and confirm data passing to configuration software before shipping. Test reports available.
