3. Key Technical Specifications
- Input Voltage: 85 to 264 Vac rms (universal AC), 47 to 63 Hz
- Output: Regulated voltages for 3500 series modules (self-monitored)
- Module Height: Half-height (installs in designated left-side rack slots)
- Rack Compatibility: 3500/05 full-size or mini-rack
- Redundancy: Supports one or two supplies in any AC/DC mix
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
- Weight: Approx. 1.39 kg (3.06 lb) per supply configuration
- Dimensions: Fits standard 3500 rack slots (120.7 mm height reference)
- Status Indication: Green Supply OK LED on front panel
- Protection: Self-monitoring for output voltage specs
4. Product Introduction
The Bently Nevada 350015-05-00-01 is a dual universal AC power supply module for the 3500 Series Machinery Protection System. It installs in the designated left-side slots of the 3500 rack and converts 85-264 Vac input to the voltages required by monitors, TDI modules, and I/O cards.
In field use on 3500 racks, this supply delivers reliable power with built-in redundancy options. It handles full rack load when paired or used singly and includes front-panel OK LED status. Engineers choose it for its wide input range and proven performance in continuous monitoring applications.
- 350015-05-00-01
- 350015-05-00-01
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No Supply OK LED | Input power missing | ✅ High | Measure 85-264 Vac at input terminals with multimeter | Verify plant power feed and fuses first |
| Supply OK LED off after power applied | Internal failure or overload | ✅ High | Check output voltages on backplane test points | Replace power supply module |
| Intermittent rack faults | Loose power connections | ❌ Medium | Inspect wiring and seating in rack slots | Reseat module and check terminal torque |
| Redundant supply not sharing load | Configuration mismatch | ✅ Medium | Confirm both supplies show OK LEDs | Verify second supply input and seating |
| High temperature alarm | Blocked ventilation | ❌ Low | Check rack fans and ambient temp | Address cooling before replacing supply |
Contact technical support with photos of the rack LEDs, diagnostic logs from the TDI, and measured input voltages if issues persist.
6. Frequently Asked Questions (FAQ)
Is this 350015-05-00-01 a direct replacement for older 3500/15 supplies? Yes. It matches the universal AC configuration (option 05) and drops into the same half-height slots. Match the exact part number suffix when replacing to avoid input voltage surprises.
Can I hot-swap this power supply? No. Kill power to the rack or use the redundant supply first. Hot-swapping risks backplane disruption and possible damage. Always follow the 3500 manual shutdown procedure.
What does “New Original / New Surplus” mean for this unit? It is genuine Bently Nevada stock, never installed in the field. We perform full inbound inspection, power-on testing in a 3500 rack, and functional verification before shipping.
How long is the lead time? Units are in stock and ship same or next business day. We maintain inventory of common 3500/15 configurations for urgent downtime needs.
Does this support redundant operation? Yes. The 3500 rack accepts two supplies. Either can power the full rack. The 350015-05-00-01 works in any mix with other AC or DC versions.
What firmware or configuration is needed? No firmware on the power supply itself. It is plug-and-play. The rack TDI or configuration software handles monitoring of the supply status.
What warranty do you offer? 1-year warranty on tested functional performance. We provide test reports with each unit. Contact us if you need extended coverage.
Why buy surplus instead of direct from the OEM? We offer immediate availability at lower cost while maintaining the same OEM quality through rigorous testing. Many plants use these successfully for years.
