3. Key Technical Specifications
- Model Code: 350033-1-00
- Channels: 16 independent relays
- Relay Type: Form-C SPDT contacts
- Logic: Programmable Alarm Drive per channel
- Module Size: Full-height
- Power Usage: 5.8 watts typical
- Operating Temperature: -30°C to +65°C
- Indicators: Front panel LEDs for status
- Wiring: Rear I/O terminal connections
- Application: Alarm and trip interfacing
4. Product Introduction
The Bently Nevada 350033-1-00 is the 16-Channel Relay Module for the 3500 rack. It supplies 16 independent Form-C relays that activate based on configured alarm logic from other modules.
This is the standard configuration used for hard-wired outputs in protection schemes. It gives operators and control systems reliable contact closures without depending on communications.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| Relay stays open/closed | Logic not triggered | ✅ High | Force test in configuration software | Review and update alarm assignments |
| No output on terminals | Field wiring fault | ✅ High | Measure voltage or continuity at I/O | Check and tighten terminal screws |
| Module LEDs off | Power or insertion issue | ✅ High | Verify rack supply and seating | Reseat the module |
| Random activation | Ground loop or noise | ✅ Medium | Inspect shielding and grounding | Improve wiring practices |
| Contact chatter | Low coil voltage | ❌ Medium | Measure supply to module | Confirm stable rack power |
Document current configuration, LED states, and wiring photos when seeking help.
- 350033-1-00
- 350033-1-00
6. Frequently Asked Questions (FAQ)
Is 350033-1-00 the same as 350033-01-00? Yes. The -1-00 is a common shorthand for the standard 16-channel version.
How many external devices can one module control? Up to 16 separate circuits. Relays can also be paired if DPDT-like behavior is needed.
Does this module support failsafe operation? Yes. You can configure relays to de-energize on alarm or power loss depending on your safety philosophy.
Can I add this to an existing 3500 rack? Yes. Install in an available full-height slot and configure the logic through the software. No rack power cycle required for addition in most cases.
What is the contact rating? Suitable for typical industrial control voltages and currents. Always check the exact datasheet for your load type.
Do you test every relay channel? Yes. We command each relay individually and verify contact state changes during functional testing.
Why keep spares of the 350033-1-00? Relay contacts see mechanical wear over time. A tested spare lets you restore full annunciation and trip capability quickly.
