B&R 5AP1120.0702-000 7-Inch Automation Panel 1000 HMI Display

  • Model: 5AP1120.0702-000
  • Brand: B&R Automation (Bernecker + Rainer / ABB)
  • Series: Automation Panel AP1000 Series
  • Core Function: Displays plant visualization and receives operator touch inputs.
  • Product Type: 7.0″ WVGA TFT Touch Screen HMI Panel
  • Key Specs: 800 x 480 Resolution | Analog Resistive Single-Touch | IP65 Front Protection
  • Condition: New Original / New Surplus (Never refurbished, zero scratches or display wear)
  • Inventory Status: Active lifecycle part; critical buffer stock available for instant emergency dispatch.
Get a Quote
Categories: , , , , , SKU: 5AP1120.0702-000 Brand:

Description

  1. Key Technical Specifications
Parameter Specification
Part Number 5AP1120.0702-000
Manufacturer B&R Industrial Automation / ABB
Display Diagonal 7.0 inches (16:10 aspect ratio)
Display Type TFT Color LCD with LED Backlight
Resolution 800 x 480 pixels (WVGA)
Touch Technology Single-touch (analog resistive)
Front Bezel Naturally anodized aluminum (Dark Gray RAL 7024)
Ingress Protection IP65 (Front side) / UL Type 4X
Compatibility B&R Panel PC 2100 / PPC2200 / SDL/SDL3 Link Modules
Backlight Lifetime 50,000 hours minimum half-life
Dimensions (W x H) 212 mm x 156 mm
Operating Temperature 0°C to +55°C (32°F to 131°F)
  1. Product Introduction & Supply Chain Strategy

This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability. The B&R Automation 5AP1120.0702-000 Automation Panel 1000 provides high-resolution operator visualization and touch-input control for machinery driven by Panel PC 2100/2200 system architectures or remote link modules.

From a supply chain perspective, securing a factory-sealed 5AP1120.0702-000 unit prevents severe downtime when an operator interface screen suffers physical damage, backlight failure, or touch digitizer drift. Re-using refurbished or pulled display panels presents massive operational risks: micro-cracks in worn resistive touch layers and degraded LED backlights frequently lead to touch unresponsiveness and unreadable operator screens. Purchasing New Surplus inventory guarantees original display brightness, absolute touch responsiveness, and an extended service life without paying full OEM list prices.

  1. Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

  1. Disconnect main power from the control cabinet and follow strict Lock-Out/Tag-Out (LOTO) procedures.
  2. Put on a grounded ESD wrist strap before handling the replacement panel and rear electronics.
  3. Verify cabinet cutout dimensions (212 mm x 156 mm profile) and clean seal mounting surfaces.

Stage 2: Removal

  1. Unplug the backplane link cable (SDL/SDL3) or Panel PC unit attached to the rear of the panel.
  2. Loosen and remove the mounting clamps along the perimeter of the existing display.
  3. Push the damaged panel forward out of the cabinet cutout while supporting the front glass.

Stage 3: Installation (Clone & Seat)

  1. Check that the front sealing gasket on the 5AP1120.0702-000 is seated smoothly without twisting.
  2. Insert the panel into the cabinet cutout from the front side.
  3. Attach and hand-tighten the retaining clamps evenly around the frame to secure IP65 front-panel sealing.

Stage 4: Power-On & Testing

  1. Reattach the Panel PC engine or Smart Display Link receiver module to the rear interface port.
  2. Restore power to the control cabinet and boot up the system.
  3. Verify that the LED backlight illuminates brightly and perform a touch-calibration pass inside B&R Automation Studio or system diagnostic menu if prompted.
  4. Firmware/Software Versions & Upgrade Notes
  • System Integration: Operates display driver hardware transparently via attached Panel PC 2100 / PPC2200 units or SDL/SDL3 link receivers.
  • Touch Driver Support: Uses standard B&R single-touch resistive digitizer drivers built into B&R Automation Runtime and Windows Embedded/10 IoT images.
  • Hardware Revision Warning: When mounting an existing PPC2100/PPC2200 processor unit onto a new 5AP1120.0702-000 panel, ensure the rear locking slide mechanism latches fully to prevent intermittent video signal drops.
5AP1120.0702-000

5AP1120.0702-000

5AP1120.0702-000

5AP1120.0702-000

  1. Frequently Asked Questions (FAQ)

Why buy New Surplus instead of cheaper refurbished HMI panels?

Refurbished touch screens often have worn-out resistive touch digitizers and aged backlights that lose brightness quickly under industrial lighting conditions. A failing touch panel can result in operator input errors or accidental machine stops. Our New Surplus units guarantee 100% factory-new glass, bright LED backlights, and maximum touch precision.

Is the 5AP1120.0702-000 a standalone HMI computer or a display unit?

It is a display unit consisting of the 7.0″ TFT screen, touch digitizer, and front bezel. It requires a B&R Panel PC engine (e.g., PPC2100) or an SDL/SDL3 receiver module mounted to the back for processing.

Can this panel handle harsh washdown environments?

Yes. When installed correctly with a fresh gasket into a flat enclosure, the front bezel meets IP65 and UL Type 4X ratings for water and dust ingress protection.

How are these panels protected against glass damage during shipment?

Each panel is wrapped in protective anti-static film, sealed inside an ESD barrier bag, and packed in custom shock-absorbing foam inside a heavy-duty cardboard shipping box.

What warranty is provided with this unit?

This New Surplus 5AP1120.0702-000 panel includes a comprehensive 1-year functional replacement warranty along with full pre-shipment physical inspection.
