B&R 5P81451322.002-00 Power Panel Automation Panel Display

Description

1. Key Technical Specifications

1. Product Introduction & Supply Chain Strategy

This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability. The B&R Automation 5P81451322.002-00 Industrial HMI Display Panel provides high-visibility machine state monitoring and continuous operator interaction across automated assembly lines, packaging plants, and continuous process facilities.

From a strategic supply chain perspective, stocking a factory-sealed 5P81451322.002-00 panel eliminates severe downtime when a primary HMI suffers screen impact, glass cracking, or backlight burnout. Re-using refurbished display units carries high operational risks: micro-cracks in worn touch digitizers and thermal degradation of aging backlights cause dead touch zones and unreadable displays. Purchasing New Surplus inventory guarantees original factory brightness, total touch responsiveness, and an extended 10–15 year service life at a lower Total Cost of Ownership (TCO) than waiting on extended factory backorders.

5P81451322.002-00

5P81451322.002-00

1. Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

1. Disconnect main power to the control cabinet and enforce strict Lock-Out/Tag-Out (LOTO) procedures.
2. Put on a grounded ESD wristband before unpacking the replacement display unit.
3. Inspect the cabinet cutout and clean all sealing surfaces to ensure a dust- and moisture-tight seal.

Stage 2: Removal

1. Unplug power and communication cables from the rear connectors of the existing display panel.
2. Loosen and remove all retaining clamps around the perimeter of the panel.
3. Carefully press the unit forward out of the cabinet mounting cutout while supporting the front glass.

Stage 3: Installation (Clone & Seat)

1. Confirm that the perimeter sealing gasket on the 5P81451322.002-00 is seated uniformly without gaps or twists.
2. Insert the unit into the cutout from the cabinet front.
3. Attach and evenly hand-tighten the retaining clips around the frame to secure IP65 front sealing.

Stage 4: Power-On & Testing

1. Reconnect communication bus cables and secure the 24 V DC power terminal plug.
2. Restore power to the cabinet and monitor the boot sequence.
3. Confirm image clarity, backlight uniformity, and perform a touch-alignment pass in B&R diagnostic software if prompted.
4. Firmware/Software Versions & Upgrade Notes

• System Integration: Operates transparently via attached B&R system controllers or remote link interfaces.
• Driver Requirements: Compatible with standard B&R touch digitizer and display drivers within B&R Automation Studio.
• Compatibility Warning: When replacing an older generation panel, verify that the controller runtime environment supports the panel’s native display parameters to avoid screen scaling or offset issues.

1. Frequently Asked Questions (FAQ)

Why buy New Surplus instead of cheaper refurbished display units?

Refurbished HMI panels frequently suffer from aged LED backlights and worn resistive touch layers that degrade quickly in warm control cabinets. A failing touchscreen can lead to operator input errors or unintended machine stops. Our New Surplus inventory guarantees factory-new glass, bright displays, and maximum touch precision.

Is this unit complete and ready for direct installation?

Yes. The 5P81451322.002-00 is a complete industrial display assembly supplied in factory anti-static packaging, ready for drop-in replacement into standard panel cutouts.

Can this display handle harsh washdown environments?

When properly seated with an undamaged front gasket, the front bezel provides IP65 protection against dust ingress and water jets.

How is the unit protected during shipping?

Each unit is wrapped in anti-static protective film, sealed inside an ESD shield bag, and packed in heavy-duty foam insulation to prevent mechanical shock and surface damage during transport.

What warranty coverage applies to this module?

This New Surplus 5P81451322.002-00 includes a full 1-year functional replacement warranty and complete physical static test verification prior to dispatch.
