3. Key Technical Specifications
- Display: 10 inch widescreen, WSVGA resolution
- Touch: Projected capacitive multi-touch
- Processor: 800 MHz or higher
- Operating System: Windows CE 7
- Interfaces: Dual Ethernet 10/100, USB, RS232/RS485, CAN
- Power Supply: 24 VDC
- Memory: Sufficient DRAM for complex applications
- Mounting: Panel or cabinet installation
- Software: Galileo or Eaton HMI tools
- Weight: Approx. 3.4 lb
4. Product Introduction
The EATON XV-303-10-C00-A00-1B is a 10-inch multi-touch HMI from the XV300 series. It offers widescreen visualization, projected capacitive touch, and dual Ethernet ports for modern machine and process control interfaces.
This panel delivers crisp graphics and responsive multi-touch operation for operators in demanding industrial settings. It supports advanced applications with its processing power and connectivity options.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| Touch not registering | Finger/glove compatibility or calibration | ✅ High | Test with bare finger and recalibrate | Adjust touch sensitivity in settings |
| Network issues | IP conflict or cable problem | ✅ High | Check link LEDs and ping test | Verify IP, subnet, and switch ports |
| Slow screen response | High tag count or complex graphics | ✅ Medium | Monitor CPU and memory usage | Optimize project and reduce animations |
| No display output | Power or backlight fault | ✅ High | Confirm 24 VDC input | Check supply voltage and wiring |
| Communication timeout | Protocol mismatch | ✅ Medium | Review driver settings | Match PLC protocol and parameters |
Always export the current project before making changes.
- XV-303-10-C00-A00-1B
- XV-303-10-C00-A00-1B
6. Frequently Asked Questions (FAQ)
What touch technology does it use? Projected capacitive (PCT) multi-touch for smooth, gesture-capable operation.
Does it support dual Ethernet? Yes. Dual 10/100 Ethernet ports enable network separation or redundancy.
What OS runs on this panel? Windows CE 7.
Power supply requirements? 24 VDC. Ensure clean power to avoid reboots under load.
Is this suitable for outdoor or harsh environments? Indoor industrial use standard. For harsher conditions, check enclosure ratings and add protection.
Condition and testing? New Surplus stock undergoes display, touch, and communication port verification.
Warranty? 1-year warranty. Excellent choice for new installations or upgrades within the Eaton ecosystem.
