DGSRC-BA
DGSRC-BA

Enterasys DGSRC-BA SSR-8 Control Module

  • Model: DGSRC-BA
  • Brand: Enterasys
  • Series: SSR / Cabletron
  • Core Function: Chassis control and management module
  • Product Type: Supervisor / Control Module
  • Key Specs: SSR-8 compatible, system management, redundancy support
  • Condition: New Original / New Surplus
Get a Quote
Categories: , , , , SKU: DGSRC-BA Brand:

Description

3. Key Technical Specifications

Parameter Value
Module Type SSR-8 Control Module
Compatibility Enterasys SSR-8 Chassis
Management CLI, SNMP, system supervision
Redundancy Supports redundant supervisor configurations
Ports Console and management interfaces
Performance Controls switching fabric and routing functions
Operating Temperature 0°C to 40°C (chassis dependent)
Firmware Enterasys SSR software compatible

4. Product Introduction

The Enterasys DGSRC-BA is a control module designed for the SSR-8 chassis. It provides system supervision, management, and control functions for high-performance routing and switching in the chassis.

In deployments of older SSR platforms, this module handles coordination of line cards and overall system health. It remains a key component for maintaining operational legacy backbone or distribution setups.

DGSRC-BA
DGSRC-BA

5. Troubleshooting Quick Reference

Symptom Possible Cause Relevance to this Part Quick Check Method Recommendation
Module not booting Power or firmware issue ✅ High Check console output during boot Verify chassis power and load correct image
No management access Console settings mismatch ✅ High Confirm baud rate (usually 9600) Use correct terminal settings (8-N-1)
Redundancy failover failure Configuration or hardware mismatch ✅ Medium Check “show redundancy” or equivalent Ensure both modules match in firmware
High CPU on supervisor Routing table issues ❌ Low Monitor processes via CLI Clear routes or optimize configuration
LEDs not normal Hardware fault ✅ High Compare LED patterns to manual Replace if persistent after reseat
System instability Fabric communication error ✅ High Review system logs Check backplane connections

Contact technical support with console logs and “show” command outputs if diagnostics do not identify the root cause.

6. Frequently Asked Questions (FAQ)

What chassis does the DGSRC-BA work with? It is designed for the Enterasys / Cabletron SSR-8 series chassis. Confirm exact compatibility with your specific chassis revision before installation.

Does this support redundant configurations? Yes. The DGSRC-BA can operate in redundant supervisor setups for higher availability.

Is this module still supported? The SSR platform is legacy. Support is limited to existing installations. Plan accordingly for long-term maintenance.

Is this New Surplus stock? Yes, offered as New Original / New Surplus. Modules undergo functional testing in compatible chassis environments where possible.

How do I upgrade firmware on this module? Use the Enterasys SSR software tools and follow the documented upgrade procedure for the control module. Always back up configuration first.

What warranty applies? We provide a 1-year hardware warranty. Test records and photos of the module are available upon request prior to shipment.
