3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Data Rate | 40 Gbps aggregate (4 x 10 Gbps lanes) |
| Connector Type | QSFP+ to QSFP+ |
| Cable Length | 15 meters (49.2 ft) |
| Cable Type | Active Optical Cable |
| Fiber | Multimode parallel optics |
| Reach | Optimized for short to medium distances |
| Form Factor | QSFP+ MSA compliant |
| Operating Temperature | Commercial range (0°C to 70°C typical) |
| Power Consumption | Low power per QSFP+ spec |
| Compatibility | Extreme Networks switches with QSFP+ ports |
4. Product Introduction
The Extreme Networks 40GB-F15-QSFP is a 40G QSFP+ Active Optical Cable that provides a direct 40 Gigabit Ethernet connection over 15 meters. It integrates four optical lanes for high-bandwidth, low-latency links between switches, routers, or servers.
Network engineers use this AOC for cost-effective, reliable interconnects inside data centers or between racks in automation backbone applications. It eliminates the need for separate transceivers and fiber patch cords while delivering plug-and-play 40G performance.
- 40GB-F15-QSFP
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No link light | Dirty connectors or incompatibility | High | Inspect and clean QSFP+ ends | Use lint-free wipes; reseat firmly |
| Intermittent connection | Bend radius violation | High | Check cable routing | Maintain minimum 30mm bend radius |
| High error rates | Signal degradation | Medium | View interface counters on switch | Verify length within 15m spec |
| Module not recognized | Firmware or port config | Medium | Check show interfaces transceiver | Update switch firmware if needed |
| Overheating | Poor airflow | Low | Monitor module temperature | Ensure proper ventilation around ports |
| Link flaps | Power or EMI | Low | Test in different port | Isolate from EMI sources |
Capture show interface ethernet and transceiver details when reporting issues.
6. Frequently Asked Questions (FAQ)
What is the maximum supported distance for the 40GB-F15-QSFP? This 15-meter Active Optical Cable is designed for short-reach applications up to its rated length. Performance is best within that range.
Is this a passive cable or active? It is an Active Optical Cable with integrated electronics for signal regeneration, allowing reliable 40G performance over the full length.
Will it work in any QSFP+ port? It is compatible with Extreme Networks equipment supporting 40G QSFP+. Always verify port specifications and firmware support on your specific switch model.
Can I use this for 4x10G breakout? This is a standard 40G AOC. For breakout to 4x10G, use dedicated breakout cables or transceivers.
How do I clean and handle the connectors? Use fiber optic cleaning tools on the MPO-style interfaces. Avoid touching the optical surfaces and always use protective caps when not connected.
What condition are your units? New Original / New Surplus. Cables undergo continuity testing, insertion loss verification, and functional link testing with compatible Extreme hardware. Test reports available.
Is this a direct replacement for shorter 40G cables? Yes, it provides a longer-reach option. Ensure total cable length does not exceed switch port specifications and maintain proper installation practices.
