3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Ports | 48 x 10/100/1000BASE-T PoE+ |
| Uplink Ports | 4 x 10GBASE-X SFP+ (unpopulated) |
| Switching Capacity | 336 Gbps |
| Forwarding Rate | 250 Mpps |
| PoE Budget | Up to 1440W with dual high-power PSUs |
| Stacking | SummitStack support (up to 8 units) |
| Dimensions (HxWxD) | 1.73 x 17.4 x 19 inches (approx.) |
| Weight | Approx. 15-18 lb (depending on PSUs) |
| Operating Temperature | 0°C to 45°C |
| Power Supply | Dual redundant AC/DC options |
| Management | ExtremeXOS, CLI, web interface |
4. Product Introduction
The Extreme Networks X460-G2-48p-10GE4 is a 48-port Gigabit PoE+ switch with four 10G SFP+ uplink ports. It serves both advanced edge and aggregation roles in enterprise and campus networks where high port density and Power over Ethernet are required.
Technicians who have deployed these in production stacks note reliable PoE delivery and solid ExtremeXOS stability when power supplies and cabling are correctly specified. The rear VIM slot allows further expansion for additional high-speed connectivity if needed.
- X460-G2-48p-10GE4
- X460-G2-48p-10GE4
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No power to switch | PSU failure or input issue | ✅ High | Verify AC/DC input and PSU status LEDs | Swap PSU or check power redundancy |
| PoE ports not delivering power | Budget limit or port config | ✅ High | Run “show inline-power” and “show power budget” | Reduce load or add second high-wattage PSU |
| SFP+ uplink no link | Wrong optic or speed setting | ✅ High | Run “show ports” and check transceiver | Use compatible 10G optics and set speed if needed |
| Stack not forming | Cable or software mismatch | ✅ Medium | Execute “show stack” command | Match firmware and verify stacking ports/cables |
| High fan noise or overheating | Airflow obstruction | ✅ Medium | Check intake/exhaust clearance | Ensure proper spacing and clean vents |
| Intermittent connectivity | MTU or QoS misconfiguration | ❌ Low | Review logs with “show log” | Adjust MTU and test with default settings |
Contact technical support with full “show tech-support” output and photos of the installation if problems continue.
6. Frequently Asked Questions (FAQ)
Does the X460-G2-48p-10GE4 support full 10GbE uplinks natively? Yes, the four front SFP+ ports run at 10GbE. Additional high-speed ports are available through the optional rear VIM module.
What PoE budget can I actually achieve? With dual 1100W or higher power supplies you can reach up to 1440W PoE budget. Always verify the exact PSU part numbers installed in your unit.
Is stacking straightforward on this model? It supports stacking with compatible SummitStack cables. Match software versions across all stack members and use the dedicated stacking ports for best results.
Is this unit new surplus stock? Yes, this is New Original / New Surplus. It ships with full traceability from the manufacturer and passes complete port and PoE functional testing before leaving our facility.
Will my older X460 configurations migrate easily? Most configurations carry over, but review ExtremeXOS release notes for command changes and new defaults. Back up your running config first.
What kind of warranty applies? We provide a 1-year hardware warranty. Test reports and detailed photos of the unit are available upon request prior to shipment.
Can I mix power supply types? Use matching power supplies for proper redundancy. Refer to the hardware installation guide for supported combinations and airflow directions.
