GE BRICK-4-HI-S-CV50-S-X-X Multilin HardFiber Brick Process Interface Unit

  • Model: BRICK-4-HI-S-CV50-S-X-X
  • Brand: GE Multilin
  • Series: HardFiber System
  • Core Function: Process interface for switchyard signals
  • Product Type: HardFiber Brick (Process Interface Unit)
  • Key Specs: HI power, CV50 voltage/current inputs, hardened design
  • Condition: New Original / New Surplus
Get a Quote
Categories: , , , , SKU: BRICK-4-HI-S-CV50-S-X-X Brand:

Description

3. Key Technical Specifications

  • Model: BRICK-4-HI-S-CV50-S-X-X
  • Type: S-Brick Process Interface Unit
  • Power: HI range control power
  • Inputs: Configured for current and voltage (CV50)
  • Communication: Fiber optic to central unit
  • Design: Switchyard hardened for outdoor/marshaling cabinet use
  • Application: Digital substation HardFiber architecture
  • Mounting: Inside marshalling cabinets or kiosks

4. Product Introduction

The GE Multilin BRICK-4-HI-S-CV50-S-X-X is a HardFiber Brick process interface unit that digitizes analog signals from CTs and VTs in the switchyard and transmits them over fiber to the central relay. It eliminates copper wiring runs between the yard and control house.

This architecture improves safety, reduces installation costs, and increases reliability in modern digital substations. Match the exact order code options to your system design for seamless integration.

BRICK-4-HI-S-CV50-S-X-X
BRICK-4-HI-S-CV50-S-X-X
BRICK-4-HI-S-CV50-S-X-X
BRICK-4-HI-S-CV50-S-X-X

5. Troubleshooting Quick Reference

Symptom Possible Cause Relevance to this Part Quick Check Method Recommendation
No communication to central relay Fiber or power issue ✅ High Check fiber link status and power LEDs Verify fiber connections and supply
Incorrect measurements Input wiring or scaling ✅ High Compare Brick readings to field instruments Check CT/VT ratios and wiring
Brick not powering up Control power problem ✅ High Measure voltage at power terminals Confirm HI range supply
Intermittent data Dirty fiber or loose connections ✅ Medium Inspect and clean fiber ends Use proper fiber cleaning tools
Alarm on central relay Brick configuration mismatch ✅ Medium Review Brick settings in software Reconfigure or replace if faulty

Use the HardFiber system diagnostics for detailed status.

6. Frequently Asked Questions (FAQ)

What is the HardFiber Brick? It is a rugged process interface unit that converts analog field signals to digital data sent over optical fiber, reducing traditional copper cabling in substations.

Why use the BRICK-4-HI-S-CV50 configuration? The CV50 option supports specific current and voltage inputs, while HI denotes the high-range power supply suitable for typical substation environments.

Is this Brick suitable for outdoor use? The HardFiber Bricks are designed for mounting in marshalling cabinets and switchyard kiosks with appropriate environmental protection.

How does it communicate? Via dedicated optical fiber links to the central Multilin relay or controller in the control house.

Is the HardFiber system still supported? Yes. It remains a viable solution for new and existing digital substation projects.

What testing is done on these units? Power supply verification, input channel testing, fiber communication checks, and environmental stress where applicable. Test reports available on request.

What should I verify before installation? Confirm fiber routing, power supply specifications, and input scaling match the system design. Follow all HardFiber installation guidelines for fiber handling and grounding. Document existing connections if replacing a unit.
