Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | DS200GGDAG1AHF |
| Manufacturer | General Electric (GE) |
| Series | Mark V Control Series (DS200) |
| Product Type | GTO Gate Driver Board |
| Application | Gas Turbine Gate Driver for Mark V turbine control |
| Category | Drive Board / Gate Driver |
| Weight | 1.00 lbs (0.45 kg) |
| Revisions | 3 total product revisions (DS200GGDAG1A, HE, HF) |
| Platform | GE Mark V Speedtronic Control System |
| Warranty (typical) | 3 years (varies by seller) |
| Status | Discontinued by manufacturer |
| Compatibility | Mark V Series turbine control systems |
Product Introduction
GE DS200GGDAG1AHF is a GTO Gate Driver Board manufactured by General Electric for the Mark V Control Series of turbine control systems. It serves as a gas turbine gate driver, providing gate drive signals for GTO (Gate Turn-Off) thyristors in power conversion and control applications
This board is selected when the existing GTO gate driver fails, shows drive signal faults, or needs replacement to maintain turbine control system operation. Buyers prioritize exact model match and revision verification (A, HE, or HF) because Mark V gate driver boards are sensitive to firmware and hardware revisions. The part is discontinued by the manufacturer, so stock is limited and typically available as New Surplus or Rebuilt.
Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to This Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| GTO does not fire despite control command | Gate driver failure, missing gate pulse, or power supply fault | ✅ High | Measure gate drive voltage at GTO gate terminal with oscilloscope | Replace GGD board if gate pulse is missing or distorted |
| Turbine control system shows gate driver fault alarm | GTO gate driver board fault or communication failure | ✅ High | Check diagnostic buffer in Mark V controller; verify board LED status | Replace GGD board if fault follows the board after reseating |
| Multiple GTOs not firing in synchronization | Gate driver board synchronization pulse failure | ✅ High | Check firing pulse timing on oscilloscope across parallel GTO boards | Replace GGD board if pulses are not synchronized |
| GTO overheats or fails prematurely | Gate driver not providing proper turn-off signal | ✅ High | Measure gate turn-off voltage and timing with oscilloscope | Replace GGD board if turn-off signal is weak or delayed |
| Board shows no activity despite power | Power supply failure or board internal fault | ✅ High | Measure input voltage at board terminals; check fuses | Replace power supply if voltage is present but board is inactive |
| Other Mark V modules also misbehave | Backplane, power supply, or system-level fault | ❌ Low | Check rack power, backplane voltage, and adjacent module operation | Do not assume GGD board is the root cause |
If you are stuck, send photos of the board, LED status, connector pins, and diagnostic logs to technical support.
- DS200GGDAG1AHF
- DS200GGDAG1AHF
Frequently Asked Questions
Q: What is GE DS200GGDAG1AHF?
A: It is a GE Mark V GTO Gate Driver Board used in gas turbine control systems. The board provides gate drive signals for GTO thyristors in power conversion applications.
Q: Is this a direct replacement?
A: Only if your existing system uses DS200GGDAG1AHF in the same Mark V configuration. There are 3 total revisions (DS200GGDAG1A, HE, HF), so verify the exact revision before installation.
Q: Is it new, used, or refurbished?
A: This part is discontinued by the manufacturer. Stock is typically available as New Surplus (unused) or Rebuilt (refurbished). Condition should be clearly stated by the seller
Q: Can I install it without changing anything else?
A: Often yes, but do not assume that. Check the original board’s revision, firmware version, and connector configuration. Mark V gate driver boards are sensitive to revision mismatches.
Q: Why is this part discontinued?
A: The Mark V series is an older turbine control platform being replaced by Mark VI and Mark VIe. Discontinued parts are sourced from remaining inventory or rebuilt units, so stock is limited.
Q: What should I check before swapping the board?
A: Photograph the old board’s revision label, note the connector positions, verify power is off, and check the backplane connector for bent pins or corrosion. A bad swap often starts with assuming revision compatibility.
Q: Why is surplus cheaper than factory stock?
A: Surplus pricing reflects secondary-market sourcing, limited availability, and discontinued status. The lower price does not mean it is the same as factory-new sealed stock, so testing and condition must be transparent.
Q: Does this part come with a warranty?
A: Warranty terms vary by seller. Some sellers offer 3-year warranty on tested units. For B2B buyers, confirm testing status, return terms, and whether a test report is included.
