3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Channels | 15 isolated analog inputs |
| Resolution | 15-bit |
| Input Types | Voltage and current |
| Input Ranges | Configurable per channel |
| Update Rate | Fast scan times |
| Operating Temperature | 0 to 60°C |
| Accuracy | High precision 15-bit |
| Isolation | Channel-to-channel |
| Mounting | VersaMax I/O station |
4. Product Introduction
The GE Fanuc IC200ALG263D is a 15-Channel Analog Input Module for the VersaMax I/O system. It accepts a mix of voltage and current signals from field transmitters and sensors.
This module delivers 15-bit resolution for accurate monitoring of process variables in industrial automation applications. It integrates seamlessly into VersaMax PLC systems for distributed I/O setups.
- IC200ALG263D
- IC200ALG263D
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No readings on channels | Wiring or power issue | ✅ High | Measure input signals at terminals | Verify 24 V DC supply and field wiring |
| Inaccurate values | Scaling or calibration error | ✅ High | Check configuration in software | Verify ranges and scaling factors |
| Channel noise | Grounding or shielding problem | ✅ Medium | Check cable shielding | Improve grounding practices |
| Module fault LED on | Internal failure | ✅ High | Review PLC diagnostics | Replace IC200ALG263D |
| Slow update | Bus or CPU overload | ❌ Low | Monitor scan times | Optimize PLC logic |
Contact technical support with configuration files and channel readings if problems continue.
6. Frequently Asked Questions (FAQ)
Is the IC200ALG263D hot-swappable? No. Power down the I/O station before replacing the module.
What condition is this unit in? New Original / New Surplus. Modules receive functional testing prior to shipment.
How many inputs does it support? 15 isolated analog input channels configurable for voltage or current signals.
What resolution does it provide? 15-bit resolution for precise measurement.
Is any configuration required? Yes. Use the VersaMax programming software to set input ranges, scaling, and alarms for each channel.
Warranty length? 1-year warranty against defects.
Common setup mistakes? Mismatched input ranges or incorrect wiring polarity. Always confirm transmitter output type matches the channel configuration.
