Key Technical Specifications
- Outputs: 8 points, 24VDC positive logic
- Output Current: 2A per point, 8A total per module
- Network: PROFIBUS-DP slave, up to 12 Mbaud auto-detect
- Connectors: M12 for PROFIBUS and I/O
- Voltage Range: 18-30VDC
- Protection Rating: IP67
- Operating Temperature: -25°C to +60°C
- Dimensions: 60 mm x 178 mm x 49.3 mm
- Weight: Approx. 0.34 kg
- Housing: Rugged metal for harsh environments
- Diagnostics: Module and channel status via PROFIBUS
Product Introduction
The GE IC676PBO082 is an 8-point 24VDC positive logic digital output module with integrated PROFIBUS-DP interface in the VersaMax IP series. It controls actuators, solenoids, and other field devices directly on the machine in distributed I/O applications.
This module delivers reliable 2A per channel output in an IP67-rated housing that stands up to washdown and vibration. It connects via M12 connectors for fast installation and supports high-speed PROFIBUS communication up to 12 Mbaud, making it a solid choice for retrofit and new decentralized control systems.
- IC676PBO082
- IC676PBO082
Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No outputs energize | No 24VDC supply or PROFIBUS not configured | ✅ High | Measure voltage at module power pins; check master configuration | Verify power and GSD file in PLC |
| Individual channel fails | Overcurrent or short | ✅ High | Monitor channel diagnostics via PROFIBUS | Check wiring and load; cycle power |
| PROFIBUS comms lost | Cable or address issue | ✅ High | Check M12 PROFIBUS connectors and baud rate | Verify termination and node address |
| Module LED not on | Power or internal fault | ✅ Medium | Confirm 24VDC at supply terminals | Replace if voltage present but no response |
| Intermittent outputs | Loose M12 connections | ✅ Medium | Inspect and reseat all M12 connectors | Torque connectors properly |
Contact technical support with module status, PROFIBUS diagnostic logs, and wiring photos if the problem continues.
Frequently Asked Questions (FAQ)
Is the IC676PBO082 new original stock? Yes, supplied as New Original / New Surplus with full OEM traceability. We run power-on and basic output tests before shipping.
What PLCs work with this module? It operates as a standard PROFIBUS-DP slave. It works with GE PACSystems, other PROFIBUS masters, and most third-party controllers that support the module GSD file.
Can I use it in wet or outdoor environments? Yes. The IP67 rating handles dust, water spray, and temporary immersion when all M12 connectors are properly mated and sealed.
What is the output current capability? Each of the 8 points supports up to 2A continuous. Total module current must stay within the power supply rating, typically 8A max.
Is hot-swapping supported on the PROFIBUS network? No. Remove power or disconnect from the bus before replacing the module to avoid bus disruptions or damage.
How do I set the PROFIBUS node address? Use the rotary switches or software configuration on the module. Always match the address in your PLC project and avoid duplicates on the network.
What warranty do you offer? We provide a 1-year warranty covering functional operation under normal conditions. Test reports are available on request.
