Key Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | General Electric (GE) |
| Part Number | IS200SCLSH1A (primary); IS200SCLSH1APR1 (revision variant) |
| Series | Mark VIe control system |
| Product Type | Core Analog Terminal Board / PCB |
| Application | Turbine control systems; serves as core analog termination interface |
| Mounting | Rack-mounted terminal board |
| Country of Origin | USA |
| Inventory Status | In Stock |
Product Introduction
GE IS200SCLSH1A is a Core Analog Terminal Board designed for GE’s Mark VIe control system. It serves as the primary analog termination interface in turbine control cabinets
For replacements, the exact suffix is critical. Match the full model number (IS200SCLSH1A or IS200SCLSH1APR1 as applicable) and verify terminal connector layout before install, because Mark VIe terminal boards can differ by revision and pinout.
Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to This Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| Analog input readings are wrong or missing | Sensor fault, wiring issue, terminal board fault, controller config mismatch | ✅ High | Check sensor output at terminal strip; verify controller diagnostics | Trace wiring and sensor before replacing board |
| Analog channels show 0 mA or 0 V | Open circuit, broken wire, power loss to sensor, board fault | ✅ High | Measure loop continuity and sensor power at terminals | Check power and continuity first |
| Intermittent analog drift | Loose terminal, noise coupling, degraded connector, board aging | ✅ Medium | Inspect terminal force, check shielding, monitor signal stability | Tighten terminals and verify grounding |
| Board fails after power-up | ESD damage, wrong revision, power issue, installation error | ✅ High | Confirm exact suffix, inspect pins, verify power rails and ESD handling | Stop—verify compatibility before retrying |
| Multiple analog channels dead | Rack backplane power issue, adjacent module fault, master controller fault | ❌ Low | Check rack power rails and status of adjacent cards | Investigate cabinet power first |
| Controller reports analog fault | Config mismatch, wrong I/O mapping, revision mismatch, board fault | ✅ High | Read diagnostic buffer and compare to cabinet documentation | Confirm config and revision match |
Contact technical support with photos of the board, terminal wiring, and controller diagnostics if you cannot isolate the fault.
- IS200SCLSH1A
- IS200SCLSH1A
Frequently Asked Questions
Q: Should I order IS200SCLSH1A or IS200SCLSH1APR1?
A: Match the exact suffix on your existing board. “PR1” is a revision suffix. If your board says IS200SCLSH1APR1, order that. If it says IS200SCLSH1A, order that. Do not substitute without verifying compatibility.
Q: What system does this board belong to?
A: It is a Mark VIe Core Analog Terminal Board for GE turbine control systems.
Q: Can I hot-swap this terminal board?
A: Do not assume so. Terminal boards route analog signals that may be tied to live sensors. Power down and follow site procedure before removal.
Q: What condition is typically available?
A: Listings show in-stock inventory. For procurement, request actual photos and test reports if you need documentation.
Q: Why is it cheaper than OEM factory stock?
A: It is usually surplus or aftermarket inventory, not current OEM production. That is normal for legacy Mark VIe parts, but you still need revision and condition verification.
Q: What should I check before installing the replacement?
A: Match the full model number (IS200SCLSH1A or IS200SCLSH1APR1), inspect terminal connectors, and follow ESD handling (grounded wrist strap). That prevents most avoidable rework
Q: What if the turbine still faults after I replace it?
A: Check sensor wiring, loop continuity, power to sensors, and controller diagnostics first. On this kind of hardware, the board is often not the root cause unless the suffix is wrong or the unit fails power-up.
