Honeywell 6580100019 Precision Industrial DCS Temperature Sensor Assembly

Description

Key Technical Specifications

Product Introduction & Supply Chain Strategy

The Honeywell 6580100019 is a precision industrial temperature sensor designed for severe-duty process monitoring across oil & gas, chemical processing, and power generation facilities. It delivers high-accuracy thermal measurement data to field transmitters and DCS I/O channels, enabling tight closed-loop loop control and preventing dangerous process thermal excursions.

Securing the 6580100019 as New Surplus ensures uncompromised sensor calibration and insulation resistance without the hidden risks of thermal drift or degradation typical of aged or field-pulled components. In continuous chemical and utility processes, sensor failure can trigger false alarms or emergency shutdowns. Procuring factory-fresh New Surplus units reduces Total Cost of Ownership (TCO) by eliminating long OEM lead times and avoiding high-risk reliance on dubious third-party repairs.

6580100019

6580100019

Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

1. Safety First: Execute Lock-Out/Tag-Out (LOTO) procedures on the associated control loop channel and isolate thermal well pressure boundaries if working directly in-line.
2. Visual Inspection: Inspect the probe stem, terminal head, and connection threads for handling damage or surface contamination.
3. ESD & Wire Prep: Wear a grounded ESD wrist strap when terminating lead wires to the field junction box or transmitter terminals.

Stage 2: Removal

1. Disconnect incoming field signal wires from the terminal block, noting wire colors and pin positions.
2. Loosen the retaining fitting on the thermowell or mounting gland.
3. Carefully extract the old sensor straight out from the thermowell to avoid bending the protective sheath or damaging internal element leads.

Stage 3: Installation (Clone & Seat)

1. Check the insertion depth of the 6580100019 probe to ensure full bottoming contact inside the thermowell for optimal thermal response.
2. Thread the sensor housing into the fitting and tighten to recommended torque specifications.
3. Terminate signal lead wires strictly following the loop wiring diagram (matching positive/negative polarity or RTD lead configurations).

Stage 4: Power-On & Testing

1. Re-energize the instrument loop channel from the DCS panel.
2. Verify ambient or process temperature readings on the local transmitter indicator and DCS operator interface.
3. Perform a loop check to ensure no open-circuit, short-circuit, or out-of-range sensor alarms are present.

Firmware/Software Versions & Upgrade Notes

• Hardware Hardware-Level Component: The 6580100019 is a direct-sensing field component and does not carry firmware or microcode.
• Transmitter Calibration Match: Ensure your connected field transmitter or DCS input module curve (e.g., Pt100, Type K, Type J) matches the sensor’s physical element configuration.
• Wiring Practice Advisory: Always use shielded twisted-pair cabling for signal extensions to minimize electromagnetic interference (EMI) from surrounding high-voltage industrial equipment.

Frequently Asked Questions (FAQ)

Q: Is this Honeywell 6580100019 unit brand new or refurbished?

A: This product is guaranteed New Surplus / Original New. It has never been deployed in an active process plant, repaired, or rebuilt. It comes clean from verified surplus inventory in factory packaging.

Q: Why choose New Surplus over a refurbished temperature sensor?

A: Refurbished or pulled temperature sensors often suffer from micro-cracks in internal insulation, junction contamination, or thermal hysteresis from prior process cycles. A drifting sensor causes inaccurate control logic and potential product quality loss. Buying New Surplus ensures original factory resistance tolerances and absolute measurement reliability.

Q: Does this sensor require a dedicated thermowell?

A: For high-pressure, high-velocity, or corrosive process streams, installing the sensor inside a suitable thermowell is recommended to protect the stem and allow sensor replacement without breaching the process line.

Q: Can I replace this sensor while the process loop is live?

A: If the sensor is housed inside a thermowell, the electrical module can be swapped safely after disconnecting its field loop signal. Always follow plant-specific safety guidelines when working in hazardous process areas.

Q: What warranty coverage comes with this module?

A: All New Surplus 6580100019 units are covered by a full 1-year functional replacement warranty starting from the date of shipment.
