- Key Technical Specifications
| Parameter | Specification |
| Part Number | T8310 |
| System Compatibility | ICS Triplex Trusted TMR System (T8300 Expander Chassis) |
| Architecture | Triple Modular Redundant (TMR) / HIFT (3-2-0 degradation mode) |
| Expansion Bus Data Rate | 250 Mbps high-speed serial interconnect |
| Interconnect Cable | TC-301 Communications Cable via T8312 Expander Interface Adapter |
| Chassis Location | Fits leftmost processor slots of Trusted Expander Chassis |
| Power Supply Input | +24 V DC (Dual redundant backplane power rails) |
| Power Consumption / Heat | 40 W maximum |
| Operating Temperature | -40°C to +85°C (-40°F to 185°F) |
| Diagnostics & Status | Front-panel LEDs for Health (Slice Green/Red), Active/Standby, Tx/Rx |
| Weight | 1.33 kg (2.93 lbs) |
- Product Introduction
The ICS Triplex T8310 (Rockwell Automation) is a dedicated Triple Modular Redundant (TMR) Expander Processor module engineered for high-integrity Safety Instrumented Systems (SIS) and critical process control. Residing in the processor slots of an expander chassis, the T8310 serves as the high-speed “slave” interface, seamlessly linking remote expansion chassis backplanes to the main Trusted controller system.
Utilizing Hardware Implemented Fault Tolerant (HIFT) technology with a 3-2-0 voting architecture, the T8310 isolates network or hardware faults locally to guarantee system availability in Emergency Shutdown (ESD), Fire & Gas (F&G), and turbomachinery control applications. Automation engineers specify the T8310 to expand system I/O channel density over long-distance cable runs without compromising microsecond-level fault containment or SIL3 safety ratings.
- Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
| Front Panel “Healthy” LED turns RED | Internal slice fault or memory voting mismatch on one of the 3 TMR channels | ✅ High | Check status LEDs in Trusted Workbench diagnostics to identify faulty slice | Perform hot-swap replacement of the faulted module using the standard ejector tool sequence. |
| TxRx LEDs Off / Bus Communication Fault | Loose TC-301 expansion cable or damaged T8312 bus adapter | ✅ High | Inspect physical cable lock mechanism and measure bus signal continuity | Re-seat TC-301 bus cables. Verify cable integrity; if cable and adapter are intact, replace the T8310 module. |
| Expander Chassis I/O Nodes Offline | Module not locked into active mode or backplane power rail drop | ✅ High | Verify Active/Standby LED status on front panel; check 24V power supply module | Ensure ejector tabs are fully latched. Confirm +24 V DC backplane power is stable. |
| Module fails to transition to Standby during hot swap | Ejector tab interlock microswitch dirty or unengaged | ✅ High | Fully open ejector tabs using the release tool to trigger standby switch | Use the proper release tool to trigger the ejector interlock switch before pulling the module from the rack. |
T8310
T8310
- Frequently Asked Questions (FAQ)
Q: Where is the module installed in a Trusted system?
A: The resides specifically in the dedicated processor slots located on the far left of a Trusted Expander Chassis (T8300 series).
Q: Can the be hot-swapped while the process is actively running?
A: Yes. The supports full online hot replacement. Releasing the top and bottom ejector tabs signals the system to transition the module into standby mode, allowing safe removal without disrupting active control loops on the expansion chassis.
Q: How does the 3-2-0 fault tolerance operate on the ?
A: The module executes triple modular redundant voting across three independent internal hardware channels (3). If a fault occurs in one channel, the module drops to 2-channel operating mode (2) without interrupting system operation. If a second failure occurs, it transitions to single-channel mode (0) while generating diagnostic alarms before requiring replacement.
Q: What cabling is required to connect the main controller chassis to the expander processor?
A: Connection between chassis assemblies requires the TC-301 hot-link communication cable coupled with the T8312 Expander Interface Adapter mounted on the chassis backplate.
Q: How are surplus or refurbished ICS Triplex modules verified before dispatch?
A: Every unit passes a strict 5-step SOP quality inspection: backplane edge connectors are cleaned and checked, the unit is inserted into a live Trusted test rack, 250 Mbps bus communication throughput and 3-channel voting logic are tested via Trusted Workbench software, a 24-hour thermal burn-in is executed, and anti-static ESD packaging is applied prior to shipment.
