Key Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Kongsberg |
| Model | HD 13T21 STD-EA1-FAGP-10051 |
| Display Family | X Series |
| Display Size | 13.3 inches |
| Product Type | Marine monitor with projected capacitive touchscreen |
| Touch Interface | Multitouch |
| Touch Connection | USB |
| Video Inputs | DVI and VGA |
| Backlight | LED |
| Display Format | Verify from the unit label or OEM datasheet |
| Intended Environment | Marine bridge, navigation, and vessel automation systems |
| K-Pos Use | Compatible display option for supported K-Pos operator interfaces; verify system revision |
| Mounting | Verify panel cutout and mounting dimensions before installation |
| Power Supply | Verify nameplate voltage and consumption before energizing |
| Environmental Approval | Verify the exact production unit’s marine approval markings |
| Connector Arrangement | Verify from rear-panel photographs |
| Operating Temperature | Verify from the exact product documentation |
| Protection Rating | Verify from the exact product documentation |
| Serial Number | Required for traceability and support |
| Condition | Must be stated as New Original, New Surplus, or Refurbished (tested) |
The available product information identifies this unit as a Kongsberg HD 13T21 display with a 13.3-inch panel, DVI/VGA inputs, USB multitouch, and LED backlighting.
Kongsberg documentation identifies a 13.3-inch HD 13T21 display as an operator-interface component in K-Master and K-Pos heading-control configurations. The DNV documentation also identifies the HD 13T21 KMD-DR1-CORx hardware family within the approved K-Pos system equipment list.
Product Introduction
Kongsberg HD 13T21 STD-EA1-FAGP-10051 is a 13.3-inch marine display with an integrated projected-capacitive multitouch interface. The STD configuration provides DVI and VGA video connectivity with a USB touch interface for vessel navigation, automation, and Kongsberg operator-station applications.
Use this display as a replacement only after checking the original unit’s power rating, panel cutout, connector layout, video format, touch interface, and system approval requirements. Kongsberg documentation places HD 13T21 displays within K-Master and K-Pos operator-interface systems.
HD 13T21 STD-EA1-FAGP-10051
Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to This Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No display or power LED | Missing supply voltage, blown fuse, or incorrect polarity | ✅ High | Measure the exact nameplate supply at the display input terminals; do not assume 24 V DC | Check vessel power distribution and fuses before replacing the display |
| Backlight is on but screen is blank | No video signal, incorrect input selection, or failed display electronics | ✅ High | Test both DVI and VGA sources and select the corresponding input | Verify the source output and cable before condemning the monitor |
| Touchscreen does not respond | USB cable disconnected, damaged touch controller, or driver issue | ✅ High | Confirm USB continuity and check whether the host detects a USB touch device | Test the USB path and host configuration before replacing the panel |
| Touch coordinates are inaccurate | Calibration loss, incorrect display orientation, or operating-system setting | ✅ Possible | Run the approved touchscreen calibration utility and check display settings | Recalibrate before replacing the display |
| Intermittent image loss | Loose DVI/VGA connector, vibration, cable damage, or supply fluctuation | ✅ High | Wiggle-test connectors with power on only where safe; measure supply during the fault | Replace damaged cables and secure connectors before replacing the display |
| Image has incorrect resolution | Host output exceeds the panel capability or incorrect graphics setting | ⚠️ Possible | Test a known-good source at the original display resolution and refresh rate | Set the host to a supported video mode from the system manual |
| Screen shows color distortion | Cable fault, connector contamination, or display electronics failure | ✅ Possible | Test with a short known-good DVI or VGA cable and inspect connector pins | Replace the cable first; then evaluate the display |
| Touch activates without contact | Moisture, contamination, grounding issue, or touch-panel fault | ✅ High | Clean and dry the panel; inspect grounding and USB cable shielding | Remove moisture and verify grounding before replacing the unit |
| Display reboots during operation | Supply sag, loose power connection, overheating, or internal fault | ✅ High | Monitor input voltage during startup and load changes; inspect ventilation | Correct the supply and thermal conditions before replacement |
| Replacement fits but will not operate | Different power, video, touch, or marine-system configuration | ✅ High | Compare nameplate data, rear connectors, cutout, and exact type code | Do not install based on screen size alone |
| System approval concern | Replacement lacks matching marine approval or documentation | ✅ High | Check certification markings and vessel-system documentation | Confirm approval requirements with the integrator, class society, or Kongsberg support |
Important: For marine installations, verify the exact display part number, serial number, supply voltage, power consumption, magnetic-compass safe distance, and approval markings. If the fault remains, provide technical support with photographs of the front and rear panels, nameplate, cables, system model, video source, and diagnostic information.
Frequently Asked Questions (FAQ)
What is Kongsberg HD 13T21 STD-EA1-FAGP-10051?
It is a Kongsberg 13.3-inch X Series marine display with a projected-capacitive multitouch interface. The available product information identifies DVI and VGA video inputs, USB touch connectivity, and LED backlighting.
Is this display used in Kongsberg K-Pos systems?
Kongsberg certification documentation identifies a 13.3-inch HD 13T21 display as an operator-interface component in K-Master and K-Pos heading-control configurations. Confirm the exact K-Pos or K-Master software and hardware revision before ordering.
Does the display support DVI and VGA?
The available listing identifies DVI and VGA inputs. Verify the rear-panel connector arrangement on the actual unit because production revisions and custom marine configurations can differ.
Does the touchscreen use USB?
Yes. The available product information identifies a factory-installed projected-capacitive multitouch panel with a USB interface. Check the USB cable, host operating system, and calibration settings if video works but touch does not.
Can I replace another 13.3-inch marine monitor with this model?
Not automatically. Match the power input, current consumption, panel cutout, mounting hardware, video interface, touchscreen interface, environmental rating, and marine approval documentation. Screen size alone does not establish interchangeability.
Is this unit suitable for a safety- or navigation-critical vessel system?
Treat it as a component requiring system-level verification. Kongsberg documentation places approved hardware within defined K-Pos configurations and installation manuals. Confirm the exact production variant, certification status, and vessel-system approval before placing it into service.
Is the unit new or refurbished?
The model number does not establish condition. State the actual status as New Original, New Surplus, or Refurbished (tested). For refurbished stock, document power-up, DVI and VGA video tests, touchscreen operation, USB detection, backlight condition, display uniformity, connector inspection, and burn-in results.
