KRONES BSAB3000-480T-300C High Voltage AC/DC Power Supply

Description

Key Technical Specifications

Product Introduction & Supply Chain Strategy

This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability.

The KRONES BSAB3000-480T-300C is a specialized high-voltage AC/DC power supply engineered to provide a stable 300 VDC bus for servo amplifiers and drive systems across KRONES high-speed bottling, labeling, and packaging machinery. Purchasing this module as New Surplus represents a critical supply chain safeguard for plant maintenance managers. Because KRONES has officially discontinued this power unit, sourcing verified New Surplus guarantees full system longevity and protection against total production line lockouts, eliminating the severe failure rates and short lifespans inherent to second-hand or refurbished power hardware with degraded internal capacitors.

BSAB3000-480T-300C

BSAB3000-480T-300C

BSAB3000-480T-300C

Installation & Configuration Guide

1.Pre-Installation (Prep & Safety):Disconnect 480 VAC power and apply LOTO.

Isolate main incoming 3-phase 480 VAC feeds and execute strict Lock-Out/Tag-Out (LOTO) procedures. Put on an ESD-grounded wrist strap and wear arc-flash safety gear. Verify complete discharge of external 300 VDC bus capacitor banks with a calibrated multimeter before touching bus terminals.

2.Removal:Unwire terminal connections safely.

Label each AC input phase and DC output cable clearly. Unfasten high-current power terminal connections and signal harnesses. Unscrew chassis mounting hardware and lift the module straight off the cabinet backplane to avoid dropping mounting fasteners into lower electronics.

3.Installation (Clone & Seat):Mount unit and double-check switch positions.

Inspect the new BSAB3000-480T-300C chassis to ensure grounding contacts are clean. Mount the module securely onto the panel enclosure, ensuring unblocked ventilation clearances above and below the heatsink. Re-attach heavy-gauge AC input and 300 VDC output cables according to original pinouts.

4.Power-On & Testing:Perform cold impedance checks and energize.

Perform a cold line-to-ground and DC bus resistance check to verify zero short circuits. Restore 480 VAC supply power. Check front status lights to verify normal bus energization and ensure no fault conditions trip the main feeder circuit breaker.

Firmware/Software Versions & Upgrade Notes

• Hardware Hardware Revision Compatibility: The BSAB3000-480T-300C operates as a hardware-level analog/power-conversion stage and does not utilize onboard user-flashable microcode or digital firmware layers.
• DC Bus Matching: Ensure the system drive controller expects a nominal 300 VDC supply bus. Interfacing this power supply with mismatched drive buses (e.g., 24V or 600V logic systems) will cause immediate hardware destruction.
• Replacement Drop-In: Verify that internal jumper blocks or auxiliary signal harnesses match the exact variant coding on your legacy module to maintain proper thermal trip feedback to the central PLC system.

Frequently Asked Questions (FAQ)

Q: Is this KRONES BSAB3000-480T-300C unit genuinely new?

A: Yes, this module is 100% Genuine New Surplus. It has never been installed in a factory environment or subjected to operational thermal cycles. We enforce a zero-tolerance standard against refurbished, rebuilt, or used equipment.

Q: Why choose New Surplus over a refurbished or repaired KRONES power supply?

A: Refurbished high-voltage power supplies often retain worn-out electrolytic capacitors, aged transformers, and thermal-stressed solder joints. While a refurbished supply might save a small amount upfront, it carries a high risk of unexpected internal short circuits, which can lead to extended downtime on a high-speed bottling line.

Q: Is the KRONES BSAB3000-480T-300C a hot-swappable module?

A: No. Under no circumstances should you disconnect or mount the while the 480 VAC main supply is live. Unplugging high-voltage DC terminals under load creates hazardous electric arc flashes and permanently damages terminal blocks.

Q: What maintenance is recommended to maximize the life of this power supply once installed?

A: Ensure cabinet cooling fans are operational and intake filters are cleaned routinely. High ambient heat severely accelerates capacitor aging inside industrial 300 VDC power supplies.

Q: What warranty coverage accompanies this New Surplus power supply?

A: Every KRONES New Surplus module includes a comprehensive 1-year functional replacement warranty. Each unit passes full insulation resistance and power continuity verification before shipment.
