NORIS NORIMOS 1000 A1 |Monitoring Panel Unit

  • Model: NORIMOS 1000 A1 (Ref: 061.079.A1 / A1-81)
  • Brand: NORIS (Noris Tachometerwerk)
  • Series: NORIMOS 1000 Monitoring System
  • Core Function: Engine monitoring and alarm panel
  • Product Type: Monitoring / Control Panel (Rack PCB Unit)
  • Key Specs: Multi-channel outputs (SA 380/1, SA 385/3, SA 387/1); Marine-grade system; PCB rack architecture
  • ⚠️ Obsolete Model – Limited Stock Available
  • Condition: Used (Surplus, decommissioned marine equipment)
Get a Quote
Categories: , , , , SKU: 1000 A1 Brand:

Description

3. Key Technical Specifications

  • System Type: NORIMOS 1000 distributed monitoring system
  • Module Type: Panel / PCB rack unit
  • Part References: 061.079.A1, A1-81
  • Associated Modules: SA 380/1 (Output B), SA 385/3 (Output D), SA 387/1
  • Application: Marine engine monitoring, alarm handling
  • Architecture: Rack-mounted PCB system
  • Weight: ~350 g
  • Manufacturing Era: Circa 1990 systems
  • Communication: Proprietary NORIS internal bus (no modern Ethernet/fieldbus)
  • Power Supply: Typically 24 V DC (verify per vessel wiring diagram)
  • Mounting: Panel/rack integration within NORIMOS cabinet



4. Product Introduction

The NORIS NORIMOS 1000 A1 is a rack-mounted monitoring panel used in legacy NORIMOS 1000 marine automation systems for engine and auxiliary equipment supervision. It interfaces with output modules such as SA 380/1 and SA 385/3 to manage alarms and signal distribution.

In field deployments, this unit is typically retained in retrofit projects where full system replacement is not viable. Its value lies in maintaining compatibility with existing NORIS infrastructure, especially on vessels where rewiring or re-certification would be cost-prohibitive.

1000 A1
1000 A1



5. Installation & Configuration Guide

Stage 1: Pre-Installation Preparation (10–15 min)

  • ⚠️ Safety First:
    • Notify bridge/engine control room
    • Isolate 24 V DC supply
    • Lock out/tag out
    • Wait 5 minutes for capacitor discharge
  • Tools Required:
    • ESD wrist strap
    • PH1 screwdriver
    • Multimeter (Fluke 115 or equivalent)
    • वायर labels
    • Smartphone (critical for documentation)
  • Data Backup:
    • Photograph wiring terminals and module layout
    • Document all connected SA modules
    • Record alarm mapping (this system is not self-documenting)

Stage 2: Removing the Old Module (5–10 min)

  1. Remove front panel cover
  2. Label all wiring (especially multi-core harnesses)
  3. Disconnect terminals carefully — these older connectors become brittle
  4. Release rack locking mechanism
  5. Pull module straight out to avoid backplane damage
  6. Inspect rack connector pins
  • ⚠️ Note: Keep the original module on-site until commissioning is complete

Stage 3: Installing the New Module (10 min)

  1. Wear ESD protection
  2. Verify exact model match (A1 vs A1 variants matter)
  3. Configuration Clone (Critical):
    • Match all jumper settings (if present)
    • Replicate wiring exactly — no assumptions
  4. Insert module firmly into rack
  5. Reconnect wiring using proper torque
  • Self-Checklist:
    • Wiring matches original
    • Rack fully seated
    • No loose terminals

Stage 4: Power-On & Testing (10–15 min)

  • Pre-Power Check:
    • Verify no short circuits on 24 V rail
  • Power-On Steps:
    1. Energize panel only
    2. Observe indicator lamps (if present)
    3. Verify output signals to downstream modules
    4. Simulate alarm conditions
  • ⚠️ Troubleshooting Note:
    • No output → check SA module pairing
    • Intermittent alarms → likely contact oxidation in connectors



6. Frequently Asked Questions (FAQ)

Q1: Can I hot-swap the NORIMOS 1000 A1?
No. This is a 1990-era rack system with no hot-swap protection. Pulling it live risks backplane damage. Power down.

Q2: Is this model obsolete? Can I still get new units?
Yes, fully obsolete. What’s on the market is typically salvaged from decommissioned vessels. Availability is unpredictable and usually limited to single units.

Q3: What is the modern replacement?
There is no direct drop-in replacement. You’re looking at a system migration (often to platforms like ABB AC800M or Siemens PCS7). That means rewiring and re-certification in marine environments.

Q4: Will I lose configuration when replacing this unit?
This panel itself does not store programmable logic like a PLC CPU. However, wiring defines functionality. If you miswire it, you effectively “lose” the system behavior.

Q5: Why are these units expensive despite being used?
Simple: scarcity. When a vessel is down, operators pay for availability, not condition. A used unit that ships in 48 hours is worth more than waiting 12 weeks for redesign.

Q6: Are all NORIMOS 1000 A1 units identical?
No. Variants exist (A1-81, different SA module pairings). Always match part numbers and verify connected submodules before ordering.

Q7: What’s the most common failure mode?
Connector oxidation and relay output wear. I’ve seen units pass bench tests but fail under vibration offshore. If possible, request load-tested units with verification.
