Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | S8FS-G10024C |
| Series | S8FS-G (100W family) |
| Output Voltage | 24 VDC |
| Output Current | 4.5 A |
| Power Rating | 100 W |
| Input Voltage | 85-264 VAC universal (100-240 VAC rated) |
| Number of Outputs | 1 |
| Efficiency | 89% |
| Isolation Voltage | 3 kV |
| Operating Temperature | -20°C to +70°C (with derating) |
| Mounting Type | Chassis / direct mount |
| Dimensions | 129 mm L x 97 mm W x 38 mm D |
| Weight | 400 g |
| Approvals | CE, cURus, TUV, UL |
Product Introduction & Supply Chain Strategy
The S8FS-G10024C converts universal 85-264VAC line input into a regulated 24VDC/4.5A output, feeding PLCs, I/O racks, sensors, and control panel components across general-purpose automation systems. Its adjustable output and universal input range make it a common cross-region standard on machine builds shipped to multiple markets.
As an active-production, fast-moving part, the case for New Surplus stock here is straightforward TCO: this power supply carries no obsolescence risk, so JIT replenishment from a reliable New Surplus channel avoids tying up capital in buffer stock while still beating OEM lead times on an urgent panel repair.
Installation & Configuration Guide
Stage 1: Pre-Installation (Prep & Safety)
Lock out and de-energize the AC input circuit feeding the panel. Put on a grounded ESD wrist strap. Photograph the input and output terminal wiring before disconnecting, noting terminal screw torque if specified on the panel label.
Stage 2: Removal
Disconnect the AC input leads first, then the DC output leads. Release the DIN rail or chassis mounting clips/screws and lift the unit free.
Stage 3: Installation (Clone & Seat)
Mount the replacement S8FS-G10024C in the same chassis position, maintaining clearance for convection cooling. Land the AC input wiring first, then the 24VDC output wiring, matching polarity exactly as photographed.
Stage 4: Power-On & Testing
Before energizing, verify no continuity fault exists between output terminals and chassis ground. Apply AC input power and measure the DC output at the terminal block — it should read close to 24V before reconnecting downstream loads. If the unit has an adjustable output trimmer, set it to match the original unit’s measured output voltage before placing the panel back in service.
S8FS-G10024C
S8FS-G10024C
Firmware/Software Versions & Upgrade Notes
The S8FS-G10024C is a fixed-function analog/PWM switching power supply — it contains no firmware and requires no software configuration. There is no version compatibility concern when swapping units; a straight physical and electrical replacement is sufficient, provided the wiring and any output voltage trim adjustment match the original setup.
Frequently Asked Questions (FAQ)
Is this a new unit, or is it refurbished?
It’s New Surplus — original OEM manufacture, sealed at the factory and never installed or powered in a running system. It’s not a pulled, repaired, or cosmetically restored unit.
Is this part still in current production, or should I be stocking up before it’s discontinued?
It’s active current production from Omron — no EOL notice is in effect. Standard JIT replenishment from a reliable supplier is the right approach here rather than strategic hoarding.
Can I hot-swap this power supply while the panel is energized?
No. Always lock out and de-energize the AC input circuit before disconnecting or connecting any wiring on a power supply.
Does this unit retain any programming or configuration?
No — this is a fixed-function power supply with no memory or programmable settings beyond the physical output voltage trim, so there’s nothing to back up or reload during a swap.
What’s the warranty on a New Surplus unit?
We back New Surplus S8FS-G10024C units with a 1-2 year warranty, well short of forcing you into an unverified used-parts gamble with no warranty coverage.
How do I confirm this unit is genuine Omron and not counterfeit?
Every unit ships with an OEM packing slip, a verifiable Omron part number and serial number, and our QC test report confirming output voltage and load-test results before shipment.
