Phone: +86 16626708626Description
Key Technical Specifications
- Maximum Continuous Shaft Output Power: 750 W (1.0 hp)
- Continuous Current: 4.5 A RMS
- Peak Current: 13.5 A
- Input Power: 120/240 VAC, 50/60 Hz, 1500 VA
- Command Interface: Analog ±10 V command (this specific configuration — Parker also offered step-and-direction and other interface variants across the AR-xxE line)
- Feedback Support: Encoder feedback, including Smart Encoder and Heidenhain EnDat absolute encoder compatibility per Parker’s Aries documentation
- Configuration/Communication: RS-232/485 configuration port, LED status indicators on the drive face
- Connectors: Separate Output Power, Mains Power, Drive I/O, and Motor Feedback connectors (per Parker’s Aries Quick Reference Guide layout)
- Included Cable (per new-unit packaging): AR-x-Ax 6K Controller Cable, Parker P/N 71-021600-04 — confirm whether this ships with a used/surplus unit before assuming it’s included
- Manufacturer Status: Officially discontinued/obsolete — Parker’s own product page lists it as “not recommended for new designs,” so budget lead time accordingly if you need factory-new stock versus surplus
Note on the “-14293” suffix: this is a Parker factory configuration/option code appended to the base AR-08AE model — the base AR-08AE spec sheet (750 W, 4.5 A RMS, 120/240 VAC, analog command, encoder feedback) is well documented across multiple sources, but we don’t have an independently verified breakdown of exactly what the “-14293” suffix changes (firmware revision, feedback type variant, or a specific OEM configuration). If your application depends on a specific feedback device or firmware version, confirm the full part number against your original unit’s nameplate or Parker’s documentation before ordering, rather than assuming it’s functionally identical to a generic AR-08AE.
Product Introduction
The Parker AR-08AE-14293 is a single-axis digital servo drive from Parker’s Aries family, built to deliver up to 750 W of continuous shaft output power from a 120/240 VAC supply. It takes an analog ±10 V command signal and closes the loop using encoder feedback, with RS-232/485 available for configuration and diagnostics through Parker’s setup software.
This drive has been discontinued by Parker and is no longer recommended for new designs, which is exactly why it shows up on the surplus market — plants running legacy Aries-based motion systems need it for repair and replacement, not new builds. If you’re maintaining an existing line, this gets you a working unit without the redesign work a newer drive family would force on you.
AR-08AE-14293
AR-08AE-14293
Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| Drive shows no power/status LEDs at all | Mains power connector fault, blown internal fuse, or upstream power issue | ✅ Moderate | Verify 120/240 VAC is actually present at the Mains Power connector terminals | If input power is confirmed present and the drive still won’t light up, the drive is a strong suspect |
| Motor doesn’t move but drive shows normal status LEDs | Command signal not reaching the drive, or motor/feedback wiring fault | ❌ Low | Check the analog ±10 V command signal at the Drive I/O connector and verify motor/encoder cabling | Often a wiring or upstream controller issue rather than a drive fault |
| Motor moves erratically or loses position | Encoder feedback fault, loose connector, or noise on the feedback line | ❌ Low | Check Motor Feedback connector seating and cable shielding/routing away from power cables | Frequently a feedback wiring/EMI issue, not a drive failure |
| Drive faults out under load but runs fine unloaded | Current limit fault, undersized drive for the application, or motor mismatch | ✅ Moderate | Check the fault code via the RS-232/485 configuration interface and compare against the drive’s rated 4.5A RMS / 13.5A peak | If the application genuinely demands more than this drive’s rated output, this may not be a fault — it may be an undersized drive for the load |
| Drive won’t communicate over RS-232/485 for configuration | Wrong cable, port settings, or software version mismatch | ❌ Low | Confirm you’re using the correct AR-x-Ax controller cable and matching baud/port settings in the configuration software | Usually a cabling or software configuration issue, not a drive hardware fault |
| Physical damage, burn marks, or bulging components visible on the drive | Overvoltage event, internal component failure, or age-related capacitor degradation | ✅ High | Visual inspection of the drive enclosure and any visible components through vents | Replace the drive — don’t attempt to power up or repair visibly damaged power electronics |
If none of these checks resolve it, contact technical support with the fault code read from the drive, the exact nameplate part number (including the “-14293” suffix), and a description of the motor/encoder combination in use.
Frequently Asked Questions (FAQ)
Is this a new unit or used surplus? This unit is sold as New Surplus — genuine Parker Aries stock sourced from decommissioned equipment or excess inventory, since Parker has discontinued this model and factory-new units are no longer being produced. It’s been tested for power-up and basic function before listing. Ask if you want more detail on the specific test performed on this unit.
Why is this discontinued — should I be worried about buying it? Parker discontinued the Aries AR-series in favor of newer drive platforms, which is normal product lifecycle behavior, not a signal of a design flaw. The practical implication is that factory-new stock is gone and lead times through Parker for anything remaining run 3-4 weeks or longer when available at all — that’s exactly why surplus and tested-used units like this one matter for keeping an existing line running without a full motion-system redesign.
Does this include the controller cable? New-in-box units from Parker typically shipped with the AR-x-Ax 6K Controller Cable (P/N 71-021600-04). Don’t assume a surplus or used unit includes it — ask us to confirm what’s actually in the box before you order, especially if you don’t already have a spare cable on hand.
What does the “-14293” suffix mean, and does it matter for my application? It’s a Parker factory configuration code layered on top of the base AR-08AE drive. We can confirm the base drive’s core specs (750 W, 4.5 A RMS, analog command, encoder feedback), but we don’t have independently verified documentation on exactly what this specific suffix changes. If your system depends on a particular feedback device, firmware revision, or OEM-specific configuration, send us your original unit’s full nameplate details and we’ll confirm the match before you commit.
Is this a drop-in replacement for a failed drive in my existing system? Match the full part number, not just the base AR-08AE designation — the suffix code can reflect a configuration difference that matters for your specific motor/encoder setup. If you give us your original unit’s complete nameplate, we can help confirm compatibility before you order.
Can I hot-swap this drive while the system is powered? No — treat any servo drive replacement as a de-energized task. Disconnect mains power and follow proper lockout/tagout procedure before disconnecting or connecting the Mains Power, Motor Feedback, or Drive I/O connectors.
What’s the warranty on a surplus unit like this? Standard warranty terms apply to functional failures found after receipt within the coverage window — ask for the specific term at checkout, since surplus stock on a discontinued model typically carries a shorter warranty than what a factory-new order would have offered while this drive was still in production.
