Key Technical Specifications
| Parameter | Value |
| Manufacturer | Parker Hannifin |
| Model Number | CPAR-08AE-14293 |
| Input Voltage | 200–240 VAC, 50/60 Hz (1-Phase / 3-Phase) |
| Continuous Output Current | 8.0 A RMS |
| Peak Output Current | 16.0 A RMS (3 seconds) |
| Control Interface | Digital I/O, Analog Step/Direction, RS-232/485 Serial |
| Feedback Types Supported | Incremental Encoder, Resolver |
| Operating Temperature | 0 to 45 °C (32 to 113 °F) |
| Enclosure Rating | IP20 / Panel Mount |
| Cooling Method | Internal Heat Sink with Forced Air Fan |
| Dimensions (H × W × D) | 185 mm × 65 mm × 150 mm |
| Weight | 1.8 kg (3.97 lbs) |
Product Introduction & Supply Chain Strategy
The Parker CPAR-08AE-14293 is a compact AC servo drive engineered for high-precision velocity, position, and torque control in automated packaging, material handling, and CNC machinery. It interfaced with standard incremental encoders to provide tightly closed-loop motion control across industrial backplanes.
Securing this module as New Surplus eliminates the high Total Cost of Ownership (TCO) associated with unverified used drives or lengthy OEM lead times. Maintaining 1–2 units as buffer stock safeguards your facility against extended downtime, avoiding the catastrophic losses linked to component failures on discontinued automation platforms.
CPAR-08AE-14293
CPAR-08AE-14293
Installation & Configuration Guide
1.Stage 1: Pre-Installation (Prep & Safety):Prerequisite & LOTO.
Perform Lock-Out/Tag-Out (LOTO) on the main distribution panel. Equipping a grounded ESD wrist strap is mandatory before touching the drive electronics. Document all jumper settings, DIP switch addresses, and wiring terminals on the original drive before removal.
Verification: Confirm zero AC line voltage across the mains inputs using a digital multimeter.
2.Stage 2: Removal:5 min.
Unplug the removable screw terminal blocks and disconnect encoder/serial cables. Loosen the top and bottom panel mounting screws, then carefully lift the unit straight off the mounting plate without putting stress on internal pins.
Verification: Inspect terminal wiring connectors for heat fatigue or loose wire strands.
3.Stage 3: Installation (Clone & Seat):10 min.
Match the replacement CPAR-08AE-14293 DIP switches and configuration jumpers identically to the original unit. Mount the drive onto the backplane and tighten all chassis grounding bolts to ensure proper EMC shielding. Re-attach terminal connectors securely.
Verification: Gently tug connected terminal blocks to ensure mechanical locks are fully engaged.
4.Stage 4: Power-On & Testing:Commissioning.
Apply 24 VDC control power first to verify the internal CPU boots without fault LEDs. Once confirmed, apply main AC line power and issue a low-speed jog command via the controller interface.
Verification: Check that the status LED shows solid green (RUN state) and the motor responds without axis chatter or encoder fault alarms.
Firmware/Software Versions & Upgrade Notes
- Recommended Firmware: Firmware V2.14 or higher is recommended for full parameter set compatibility.
- Compatibility Constraints: Parameter dumps created on firmware V1.x cannot be restored directly to V2.x hardware without re-mapping the internal gain and I/O registers via Parker Motion Planner software.
- Upgrade/Downgrade Warning: Avoid flashing firmware during emergency swaps on active production lines. Firmware mismatches cause bus communications timeouts and invalid motor encoder alignment tables. Always back up the current parameter profile to a PC before replacing hardware.
Frequently Asked Questions (FAQ)
Is this Parker CPAR-08AE-14293 unit brand new or refurbished?
This unit is 100% New Surplus. It is original OEM inventory, never pulled from a decommissioned line, and never repaired or refurbished. It remains in its original anti-static packaging and underwent full ESD-safe bench inspection prior to listing.
Why buy New Surplus instead of lower-cost refurbished units on the market?
Refurbished servo drives often contain aged electrolytic capacitors and thermal paste near the end of their operational lifespan. A failed capacitor can short out internal IGBT power stages during peak torque loads, leading to unexpected plant shutdowns. Buying New Surplus guarantees factory-fresh component longevity.
How is the module tested before shipment?
Every CPAR-08AE-14293 unit goes through an inbound quality protocol. This includes visual inspection of backplane contacts, insulation continuity testing, power-on self-test, and communication loopback tests on our test rigs.
Is this drive direct plug-and-play for an existing installation?
Yes, provided you mirror the DIP switch configurations and transfer the saved parameter file from your legacy drive using Parker’s motion configuration software.
What warranty coverage is included?
We back this New Surplus unit with a comprehensive 1-year replacement warranty, giving you complete peace of mind without the lead time of ordering through standard distribution channels.
