Key Technical Specifications
| Parameter | Specification / Value |
|---|---|
| Manufacturer | Parker Hannifin |
| Part Number / Identification | AR-04AE-13574 |
| Product Type | Signal Conditioning & Logic Interface Board |
| Operating Logic Voltage | 24 V DC (Nominal logic supply rail) |
| Architecture | Multi-layer surface-mount printed circuit board |
| Signal Handling | Multi-channel discrete inputs / output drive logic |
| Mounting Format | Chassis standoffs / sub-assembly rack mounting |
| Connection Interface | Multi-pin ribbon header / screw terminal connectors |
| Operating Temperature | 0 to +55 °C (+32 to +131 °F) |
| Weight | Approx. 0.30 kg (0.66 lbs) |
Product Introduction & Supply Chain Strategy
The Parker AR-04AE-13574 is an industrial-grade electronic board engineered for logic processing, signal conditioning, and I/O interface routing in automated production machinery and drive control systems. Operating on a 24 V DC nominal logic rail, it ensures precise, noise-immune communication and signal translation between central machine processors and peripheral field actuators.
Sourcing the Parker AR-04AE-13574 as New Surplus gives plant maintenance teams and automation engineers a reliable supply chain solution for legacy machinery. Acquiring factory-fresh surplus stock guarantees clean connector pins, pristine traces, and unaged onboard components. Holding a verified AR-04AE-13574 spare in facility inventory prevents unexpected machine outages, reduces downtime risks, and lowers Total Cost of Ownership (TCO).
AR-04AE-13574
AR-04AE-13574
Installation & Configuration Guide
1
Pre-Installation & Safety Isolation
Isolate power and attach ESD protection
1.Pre-Installation & Safety Isolation:Isolate power and attach ESD protection.
- Lock out and tag out all primary and auxiliary power sources feeding the control enclosure or drive system.
- Wear an ESD-grounded wrist strap connected to cabinet earth before opening protective anti-static packaging.
- Label and photograph all cable headers and terminal locations connected to the existing board.
2
Board Removal & Mechanical Standoff Disassembly
2.Board Removal & Mechanical Standoff Disassembly:
- Unfasten retaining screws or unclip mounting standoffs securing the original AR-04AE-13574 PCB to the sub-rack frame.
- Disconnect multi-pin interface cables smoothly without pulling directly on individual leads.
- Lift out the original module and inspect the enclosure mounting surface for debris or moisture.
3
Hardware Replacement & Cable Attachment
3.Hardware Replacement & Cable Attachment:
- Align the replacement AR-04AE-13574 card over the mounting standoffs and secure it using original hardware.
- Reattach all multi-pin ribbon cables and screw terminal blocks firmly to their assigned connectors.
- Confirm that ground wire connections are securely bonded to the chassis to maintain noise immunity.
4
Power-On & Signal Logic Verification
4.Power-On & Signal Logic Verification:
- Restore 24 V DC power and confirm that onboard power/status LEDs illuminate normally.
- Cycle inputs and outputs through the controller diagnostic screen to verify channel switching logic.
- Run a complete machine sequence to ensure smooth I/O signal routing and fault-free operation.
Firmware/Software Versions & Upgrade Notes
- Revision Verification: Always verify board revision markings and silk-screened part numbers on the Parker AR-04AE-13574 PCB to ensure exact electrical parity with your existing board.
- Jumper Settings: Replicate any physical jumper or DIP switch positions from the old board to the new board before applying power.
- Cable Strain Relief: Ensure all ribbon and signal harnesses are properly routed with adequate strain relief to avoid mechanical stress on connector solder joints.
Frequently Asked Questions (FAQ)
Is this Parker AR-04AE-13574 board an authentic OEM product?
Yes. This unit is New Surplus (Original New). It is an authentic Parker component obtained from canceled machinery integration projects or strategic spare reserves, and has never been deployed in active production.
Why choose New Surplus over a refurbished or repaired card?
Refurbished electronic circuit boards often suffer from thermal fatigue, micro-fractured solder joints, and degraded components due to years of operation in hot control panels. New Surplus provides factory-original component life and maximum reliability out of the box.
Does the AR-04AE-13574 require external software programming?
In most applications, this board functions as an I/O signal interface and logic routing hardware module. Logic commands are driven by the primary Parker drive controller or host PLC, so separate software programming is generally not required.
What is the primary operational voltage for this module?
The board logic operates on a standard 24 V DC nominal control supply rail.
What warranty is provided with this unit?
We back this unit with a 1-Year Comprehensive Replacement Warranty. Every AR-04AE-13574 board undergoes visual inspection and power continuity validation prior to shipment.
