Key Technical Specifications
| Parameter | Specification |
| Manufacturer | Applied Materials (AMAT) / AKT |
| Part Number | 0100-71278 |
| System Compatibility | AKT 15K, 25K, 55K, and 60K CVD/PECVD Platforms |
| Bus Architecture | VMEbus Standard (6U Form Factor) |
| Expansion Capability | Supports dual PMC (PCI Mezzanine Card) modules |
| Primary Application | Chamber-to-mainframe communication & sensor data aggregation |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | −20°C to +85°C (−4°F to 185°F) |
| Environmental Hardening | ESD-protected logic gates & high-EMI plasma chamber resistance |
| Connector Interface | Dual 96-pin DIN backplane connectors + PMC mezzanine headers |
Product Introduction & Supply Chain Strategy
This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned fab tool, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability. The Applied Materials 0100-71278 VME Communication Interface Board acts as the central communication backbone for AKT Chemical Vapor Deposition (CVD) and Plasma-Enhanced CVD (PECVD) processing systems, routing real-time data between PMC mezzanine cards and tool mainframes.
From a Total Cost of Ownership (TCO) perspective, stocking a verified New Surplus 0100-71278 board is a vital insurance policy against line-stop incidents in high-volume display and wafer manufacturing. Because OEM factory support for legacy AKT platforms is constrained, a single board failure can cause cleanroom tool downtime exceeding $50,000 per hour. Maintaining 1–2 units in safety stock eliminates lead time variability while protecting against the intermittent data corruption and dried electrolytic capacitors inherent in low-quality refurbished boards.
Installation & Configuration Guide
Stage 1: Pre-Installation (Prep & Safety)
- Execute Lock-Out/Tag-Out (LOTO) procedures on the AKT tool control cabinet and main system power.
- Put on a grounded ESD wrist strap connected to the tool chassis frame.
- Take clear reference photos of all installed PMC cards, jumper positions, and DIP switches on the existing 0100-71278 board.
Stage 2: Removal
- Unfasten the front-panel retaining thumb screws on the VME card cage.
- Release the top and bottom ejector handles simultaneously to unseat the 96-pin DIN backplane connectors.
- Slide the board straight out along the chassis card guides and place it immediately on an ESD-safe mat.
Stage 3: Installation (Clone & Seat)
- Verify that the PMC expansion daughtercards (e.g., 0100-71267) are transferred to the new 0100-71278 board, aligning PMC headers and tightening all four standoff screws securely.
- Match all jumper settings and DIP switches on the new board to replicate the original system address and baud configuration.
- Align the new module with the VME chassis guide rails and push steadily until the backplane connectors seat fully, then lock the ejector handles into place.
Stage 4: Power-On & Testing
- Measure the backplane 5 V DC and 12 V DC rails for short circuits prior to powering up the card rack.
- Apply system power and monitor the front-panel status LEDs to ensure the module completes its hardware initialization sequence without fault.
- Boot the AKT tool control software and verify active communication handshakes with chamber sensors and subsystem CPUs.
0100-71278
0100-71278
Firmware/Software Versions & Upgrade Notes
- Recommended Revision: Revision 01 (or matching the fab’s tool release baseline).
- Compatibility Considerations: The 0100-71278 board serves as a hardware carrier. While the physical VME layout is uniform across AKT 15K through 60K platforms, onboard EPROMs or attached PMC cards carry tool-specific firmware versions.
- Firmware Swap Warning: When swapping hardware during an emergency repair, transfer the socketed EPROMs or non-volatile logic chips from the failed board to the replacement board if custom fab configurations were loaded. Avoid upgrading software or firmware versions during a hardware swap to prevent protocol timeouts with legacy auxiliary CPUs (such as the 0100-71229).
Frequently Asked Questions (FAQ)
Is this Applied Materials 0100-71278 board genuine New Surplus? Yes. This module is 100% Genuine New Surplus. It has never seen production hours in a wafer fab or flat-panel cleanroom and was sourced from verified capital equipment reserves. We strictly enforce a zero-tolerance policy against second-hand, pulled, or refurbished components.
Why should I buy New Surplus over cheaper refurbished options on the market?Refurbished semiconductor boards often suffer from latent ESD damage, degraded solder joints, or aged capacitors that fail under high thermal loads near CVD processing chambers. A 20–30% premium for New Surplus buys factory-original reliability, full service life, and protection against catastrophic cleanroom downtime.
Is the AMAT 0100-71278 an obsolete or end-of-life (EOL) part? Yes. Applied Materials / AKT legacy VMEbus components are mature platforms with limited OEM production. Sourcing New Surplus units is critical for fabs maintaining older 15K–60K lines to prevent supply chain bottlenecks when board failures occur.
Can I hot-swap this board while the VME chassis is powered? No. Hot-swapping 6U VME modules without hot-swap backplane support can induce ground bounce, arc pins, and permanently destroy delicate CMOS logic ICs on both the board and the backplane. Always de-energize the rack before extraction.
Does this board come with PMC expansion cards installed?The 0100-71278 functions primarily as the VME motherboard and PMC carrier. Depending on stock configuration, it can be supplied as the base motherboard or pre-equipped with matching PMC cards (such as the 0100-71267) per tool requirements. All shipments include a 1-year functional replacement warranty backed by complete ESD testing.
