3. Key Technical Specifications
- Power Input: 100-240 VAC, 50/60 Hz, 50 W
- Dynamic Signal Channels: Up to 24
- Process Variable Inputs: Up to 24
- Keyphasor Inputs: Supports multiple synchronized inputs
- Communications: Dual Ethernet, Modbus, secure data transfer
- Operating Temperature: -30°C to +65°C
- Dimensions: 384 x 216 x 136 mm
- Weight: Approx. 4.0 kg
- Mounting: Rack or enclosure compatible
- Compatibility: Works with 3300 and 3500 machinery protection systems
- Security Features: Cyber-secure gateway design
4. Product Introduction
The Bently Nevada 2155-40-01 is the TDISecure Communication Processor with AC power input. It serves as a secure interface that collects high-fidelity vibration and process data from 3300 or 3500 systems and forwards it to System 1 or other host platforms without direct Ethernet exposure of the protection system.
This unit replaces older TDXNet processors with improved data collection rates for both steady-state and transient conditions. In plant environments, it provides the bridge for reliable, protected machinery health data. Confirm exact system compatibility and cybersecurity requirements with the current Bently Nevada documentation before deployment.
- 2155-40-01
- 2155-40-01
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No power LED | AC supply problem | ✅ High | Measure 100-240 VAC at input terminals | Verify power source and fuse |
| No communication | Network configuration | ✅ High | Check Ethernet link lights and IP settings | Use configuration software to verify addresses |
| Missing channels | Input configuration error | ✅ Medium | Review channel setup in software | Confirm sensor wiring and scan settings |
| Data dropout | Synchronization issue | ✅ Medium | Check Keyphasor signal quality | Verify tachometer or Keyphasor connections |
| High temperature | Poor ventilation | ✅ Low | Monitor internal temps via software | Improve airflow around the unit |
Contact support with error logs, network diagnostics, and photos of the installation if the issue remains unresolved.
6. Frequently Asked Questions (FAQ)
What power does the 2155-40-01 require? It uses 100-240 VAC, 50/60 Hz. This is the AC input version. Ensure stable supply with proper grounding.
Is the TDISecure hot-swappable? No. Follow proper shutdown procedures for the connected monitoring system before replacing the processor.
How many channels does it support? Up to 24 dynamic analog signal channels plus 24 process variable inputs. Actual capacity depends on the connected protection system.
Does this provide cybersecurity features? Yes. It acts as a secure gateway that isolates the machinery protection network from the plant IT network.
Can it replace an older TDI or TDXNet? Yes. It is the modern secure replacement. Migration may require configuration updates and verification of data mapping.
What software is needed for setup? Use the Bently Nevada configuration tools for the TDISecure and System 1 for data integration. Firmware updates should only be performed per OEM guidelines.
What is the condition and availability of this unit? New Original / New Surplus with immediate availability. Each unit receives inspection and basic functional checks before shipping.
