3. Key Technical Specifications
- Input Voltage: 85 to 264 Vac rms (universal AC), 47 to 63 Hz
- Input Current: 2.8 A rms maximum
- Configuration: Dual supplies (both slots universal AC)
- Agency Approvals: ATEX/IECEx and Chinese NEPSI hazardous area
- Module Height: Half-height for designated left rack slots
- Redundancy: Full support, any supply powers complete rack
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
- Status Indication: Supply OK LED on front panel
- Weight: Approx. 1.39 kg per supply assembly
- Rack Compatibility: Standard 3500/05 full or mini racks
4. Product Introduction
The Bently Nevada 350015-05-05-CN is a dual universal AC power supply for the 3500 Series Machinery Protection System. It includes two universal AC supplies rated 85-264 Vac and carries ATEX/IECEx plus Chinese NEPSI hazardous area approvals. It installs in the left-side slots of the 3500 rack.
This version suits plants with certified hazardous locations. It provides stable power with redundancy and self-monitoring. We test these in live racks to confirm full functionality before shipment.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| Supply OK LED not lit | No input voltage | ✅ High | Measure AC voltage at input terminals | Confirm certified power feed meets 85-264 Vac |
| Redundant supply alarm | Single feed issue | ✅ High | Verify both input sources | Check dual circuit breakers and wiring |
| Module not recognized | Poor seating | ✅ Medium | Inspect physical installation | Power down and reseat firmly |
| Over temperature | Restricted airflow | ❌ Low | Check rack fans and ambient conditions | Improve ventilation in hazardous enclosure |
| Certification-related fault | Improper grounding | ✅ Medium | Verify grounding per NEPSI/ATEX | Follow hazardous area installation manual |
Send diagnostic logs, photos of LEDs, and installation details if the issue remains unresolved.
- 350015-05-05-CN
- 350015-05-05-CN
6. Frequently Asked Questions (FAQ)
What do the -CN approvals mean for this 350015-05-05-CN? It carries ATEX/IECEx and Chinese NEPSI certifications for use in hazardous areas. Always install per the specific approval requirements and local codes.
Is this the same as the standard 350015-05-05-00? Functionally yes for power delivery. The -CN adds the hazardous location markings. Use this one where certifications are required for the site.
Can I hot-swap in a hazardous area? Only if the rack remains powered by the redundant supply and procedures allow it. Follow full hazardous area safety protocols including permits.
What input power setup works best? Dual independent AC feeds in the 85-264 Vac range. This maintains redundancy even during a feed loss. Size circuits for 2.8 A rms per supply.
How does availability look for this certified version? We keep stock of common certified 3500 spares. Contact us for current lead time on the 350015-05-05-CN specifically.
Will this work in a non-hazardous rack? Yes. The approvals do not prevent use in general purpose areas. It functions identically to the non-certified version.
What testing do you perform on these units? We verify input acceptance, output voltages, LED status, and run under load in a 3500 rack. Test reports available on request.
