EATON XV-112-DB-70TWRC-00 XV100 Touch Panel HMI

  • Model: XV-112-DB-70TWRC-00
  • Brand: EATON
  • Series: XV100 / Micro Panel
  • Core Function: Touchscreen operator interface
  • Product Type: HMI Touch Panel
  • Key Specs: 7″ display, resistive or similar touch, 24 VDC
  • Condition: New Original / New Surplus
Get a Quote
Categories: , , , , , SKU: XV-112-DB-70TWRC-00 Brand:

Description

3. Key Technical Specifications

  • Display Size: 7 inch
  • Touch Type: Touch panel (resistive or projected per variant)
  • Resolution: Standard XV series (typically WVGA or similar)
  • Power Supply: 24 VDC
  • Processor: 32-bit, high-performance CPU
  • Memory: DRAM onboard for applications
  • Interfaces: Ethernet, USB, RS232, CAN
  • Mounting: Back mounting in cabinets or panels
  • Operating System: Windows CE or equivalent runtime
  • Orientation: Supports portrait and landscape

4. Product Introduction

The EATON XV-112-DB-70TWRC-00 is a 7-inch touch panel from the XV100 series designed for machine visualization and operator control in industrial environments. It combines a high-resolution display with robust touch input for reliable HMI applications.

This panel is popular in OEM machinery and process lines where a compact yet capable interface is needed for parameter entry, alarms, and real-time monitoring. Its back-mount design allows flexible installation in control panels.

XV-112-DB-70TWRC-00
XV-112-DB-70TWRC-00
XV-112-DB-70TWRC-00
XV-112-DB-70TWRC-00

5. Troubleshooting Quick Reference

Symptom Possible Cause Relevance to this Part Quick Check Method Recommendation
Touchscreen unresponsive Calibration drift or overlay damage ✅ High Recalibrate via software tool Clean screen and recalibrate
Display blank Power or backlight failure ✅ High Measure 24 VDC supply voltage Check power connections and fuses
No network connectivity IP configuration error ✅ Medium Verify Ethernet link LEDs Confirm IP settings and cable
Slow performance Application overload ✅ Medium Check memory usage in runtime Optimize graphics and reduce tags
Intermittent reboot Power supply instability ✅ High Monitor voltage fluctuations Use stabilized 24 VDC supply with filtering

Perform full backup of the project before any service.

6. Frequently Asked Questions (FAQ)

What is the display size and type? 7-inch touchscreen with support for color graphics suitable for industrial HMI use.

Is this panel back-mount or front-mount? Designed for back mounting in control cabinets or desks, supporting horizontal or vertical orientation.

What software is used to program it? Eaton’s Galileo or current equivalent HMI configuration software.

Power requirements? 24 VDC. Calculate total system consumption including any expansion.

Is PLC functionality built-in? Some XV series models support optional PLC runtime. Confirm for your exact configuration.

Condition and testing? New Surplus units are powered up and tested for display, touch, and communication ports. Project upload/download verified where possible.

Warranty? 1-year warranty. Good candidate for upgrades to newer Eaton XV or XV300 series if long-term support is a concern.
