Emerson 1C31192G01 Ovation Speed Detector Personality Module

Parameter Specification
Manufacturer Emerson
Order number 1C31192G01
Product type Speed Detector Personality Module (PMOD)
Control platform Emerson Ovation DCS
Interface function Speed Detector Interface
Channels 8
Companion electronics module 1C31189G01
Input signal type Sinusoidal or pulse-train tachometer signal
Speed output 16-bit output, updated at 5 ms intervals
System role Converts tachometer frequency into controller speed data

Description

Core Product Summary

The Emerson 1C31192G01 is the Speed Detector Personality Module (PMOD) for the Emerson Ovation distributed control system. It forms the field-interface portion of an 8-channel Ovation Speed Detector Interface and works with the 1C31189G01 Speed Detector Electronics Module.

The assembly measures frequency from sinusoidal or pulse-train tachometer signals and provides speed information to the Ovation controller. Its 16-bit speed output updates at a 5 ms interval, supporting speed-regulation and overspeed-detection functions in rotating-equipment applications. The 1C31192G01 must be installed with its matching electronics module and the appropriate Ovation I/O base configuration.



Key Technical Specifications

Parameter Specification
Manufacturer Emerson
Order number 1C31192G01
Product type Speed Detector Personality Module (PMOD)
Control platform Emerson Ovation DCS
Interface function Speed Detector Interface
Channels 8
Companion electronics module 1C31189G01
Input signal type Sinusoidal or pulse-train tachometer signal
Speed output 16-bit output, updated at 5 ms intervals
System role Converts tachometer frequency into controller speed data



Engineering Selection Highlights

  • The 1C31192G01 is a personality module, not a standalone speed-measurement card; it requires the 1C31189G01 electronics module to form a functioning Speed Detector Interface.
  • Its 8-channel Speed Detector Interface configuration suits applications where multiple tachometer-derived speed signals must be brought into an Ovation controller.
  • The module accepts sinusoidal or pulse-train tachometer signals, so sensor signal type should be confirmed before selecting field wiring and termination.
  • The 16-bit speed output updates every 5 ms, which is relevant when the controller uses the speed value for regulation or overspeed-related logic.
  • Ovation I/O architecture separates the electronics module from the personality module; both must be specified and installed as a matched pair.
  • The module installs in an Ovation I/O base unit, so base-unit compatibility and project I/O configuration should be checked during replacement or system expansion.



System Compatibility & Integration Requirements

Item / Dependency Verified Compatibility or Requirement Practical Note
Control platform Emerson Ovation DCS The module is part of the Ovation I/O subsystem.
Electronics module 1C31189G01 Speed Detector Electronics Module The 1C31192G01 is the personality module for this electronics module.
Interface configuration 8-channel Speed Detector Interface The paired modules provide eight speed-detector channels.
Input signal Sinusoidal or pulse-train tachometer Confirm that the field speed sensor produces a compatible signal type.
Controller data 16-bit speed output, 5 ms update interval Use this output characteristic when configuring speed-related control logic.
Mounting Ovation I/O base unit The module must be installed in the appropriate Ovation I/O base configuration.



Dimensions, Mounting & Connection Notes

The 1C31192G01 is installed as the personality-module portion of an Ovation Speed Detector Interface. It mounts in an Ovation I/O base unit together with the 1C31189G01 electronics module, and its field connections are made through the personality-module interface rather than directly to the controller.

Exact module dimensions, terminal assignments, wire sizes, torque values, and clearance requirements should be taken from the applicable Ovation installation documentation for the installed I/O base and electronics-module revision.

1C31192G01

1C31192G01

1C31192G01

1C31192G01

Detailed Product Overview

The Emerson 1C31192G01 belongs to the Ovation I/O module architecture, where specialized measurement functions are implemented as a paired electronics module and personality module. In this arrangement, the 1C31192G01 is the Speed Detector Personality Module and the 1C31189G01 is the associated Speed Detector Electronics Module. The personality module provides the field-interface role, while the electronics module performs the speed-measurement processing.

The complete Speed Detector Interface provides eight channels and measures the frequency of sinusoidal or pulse-train tachometer signals. This allows speed information from rotating equipment to be presented to the Ovation controller in a form suitable for monitoring, regulation, and protective logic. The interface provides a 16-bit speed output with a 5 ms update interval; this update characteristic is important when evaluating how quickly the controller receives changes in measured speed.

For procurement and maintenance, the important identification point is that the 1C31192G01 is not a general-purpose input card. It is specifically the personality module for the Ovation Speed Detector Interface and is paired with the 1C31189G01 electronics module. A replacement should therefore be evaluated as part of the complete speed-detector assembly, including the electronics module, I/O base, field tachometer wiring, and controller I/O configuration.

The module’s role is most relevant in systems where shaft or rotational speed must be measured from a tachometer signal and used by the Ovation control system. Because the interface is defined for sinusoidal or pulse-train tachometer inputs, the installed speed sensor’s output type should match the configured speed-detector application before the channel is placed in service.



Applications & System Role

Within an Ovation control system, the 1C31192G01 provides the field-interface layer for speed detection. The paired 1C31189G01 electronics module processes tachometer frequency, while the 1C31192G01 personality module provides the corresponding module interface and field connection function.

The resulting Speed Detector Interface supplies speed data derived from sinusoidal or pulse-train tachometer signals. This makes the assembly suitable for rotating-equipment speed monitoring and control functions where the Ovation controller requires a speed measurement input, including speed-regulation and overspeed-detection logic.



FAQ

What is the Emerson 1C31192G01?
It is an Emerson Ovation Speed Detector Personality Module used as the field-interface portion of an 8-channel Ovation Speed Detector Interface.

Which Ovation electronics module does it require?
It pairs with the Emerson Ovation 1C31189G01 Speed Detector Electronics Module.

What does the 1C31192G01 measure?
As part of the Speed Detector Interface, it supports measurement of sinusoidal or pulse-train tachometer frequency for rotating-equipment speed determination.

How many speed-detector channels does the assembly provide?
The 1C31189G01 electronics module and 1C31192G01 personality module together form an 8-channel Speed Detector Interface.

What is the speed-output update rate?
The Speed Detector Interface provides a 16-bit speed output that updates at 5 ms intervals.

Can the 1C31192G01 operate alone?
No. It is the personality module and requires the matching 1C31189G01 electronics module to perform the speed-detector function.

Where is it installed?
It is installed in an Ovation I/O base unit as part of the Ovation I/O subsystem.
