3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Ports | 2 x 40GBASE-QSFP+ |
| Compatibility | VSP 7000 Series switches |
| Data Rate | 40 Gbps per port |
| Interface Type | QSFP+ |
| Layer Support | Supports full switch routing/switching features |
| Hot-Swappable | Yes |
| Transceiver Support | QSFP+ optics and DAC/AOC cables |
| Function | High-speed uplink / stacking MDA |
| Chassis Slot | Dedicated MDA slot on VSP 7000 |
4. Product Introduction
The Extreme Networks AL7000MV2-E6 is a 2-port 40GBASE-QSFP+ Media Dependent Adapter for the Virtual Services Platform 7000 Series switches. It adds high-speed 40 Gigabit Ethernet uplinks for core connectivity, aggregation, or inter-switch links in enterprise and data center environments.
This MDA delivers low-latency, high-bandwidth performance essential for modern networks handling virtualization, video, and large-scale traffic. It integrates directly into the VSP 7000 chassis for seamless expansion without replacing the base switch.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No link on QSFP+ ports | Transceiver/cable issue | High | Check show interfaces status and transceiver details | Verify compatible QSFP+, clean connectors, test cable |
| MDA not detected | Improper seating | High | Run show mda or equivalent CLI command | Power down, reseat firmly, and retest |
| High error rates or flaps | Dirty optics or incompatible module | Medium | Monitor interface counters and logs | Clean or replace QSFP+ transceiver |
| Reduced performance | Oversubscription or configuration | Low | Check port utilization and QoS settings | Adjust configuration or add additional MDAs |
| Intermittent operation | Thermal throttling | Medium | Verify chassis temperature and airflow | Ensure proper cooling and fan operation |
If the MDA passes self-test but ports do not link after transceiver and cable validation, provide CLI output and photos to technical support.
- AL7000MV2-E6
- AL7000MV2-E6
6. Frequently Asked Questions (FAQ)
Is the AL7000MV2-E6 hot-swappable? Yes, the MDA is designed for hot insertion and removal on the VSP 7000. Minimize traffic on the ports during the swap to prevent disruption.
What transceivers and cables work with this MDA? It supports standard 40G QSFP+ transceivers, direct attach copper cables (DAC), and active optical cables (AOC). Always check the current VSP 7000 compatibility matrix for your ExtremeXOS or VOSS version.
Can this MDA be used for stacking? It can support high-speed stacking or virtual chassis links depending on software configuration. Confirm exact stacking capabilities with your specific VSP 7000 model and firmware.
Is this module still supported? The VSP 7000 series is a mature platform. We offer new surplus stock with testing and a 1-year warranty. Ongoing software support depends on your existing service contract with Extreme Networks.
What’s the difference between this and other MDAs for the VSP 7000? This AL7000MV2-E6 provides two 40G QSFP+ ports for high-bandwidth uplinks. Other MDAs offer different port densities and speeds (such as 10G SFP+ variants). Choose based on your required connectivity.
How do I confirm compatibility before ordering? Tell us your exact VSP 7000 model and current software version. We can verify fit and any firmware considerations. Full functional testing on a VSP 7000 rig is performed before shipment.
Does this MDA support breakout cables? Some QSFP+ ports support 4x10G breakout depending on software and transceiver type. Verify the specific breakout capability in your VOSS documentation for this MDA.
