3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | A660-2006-T324L (length suffix varies) |
| Function | Teach Pendant / iPendant cable |
| Compatible Controllers | FANUC R-30iA, R-30iB and related cabinets |
| Typical Lengths | 6 m, 10 m, 12 m, 20 m (depending on exact suffix) |
| Connector Type | FANUC proprietary pendant connectors |
| Application | Robot programming and operation |
| Construction | Industrial-grade flexible cable |
| Environment | Factory floor / robot cell use |
4. Product Introduction
The FANUC A660-2006-T324L is a teach pendant cable used to connect a FANUC iPendant or teach pendant to the robot controller (commonly A-cabinet style). It carries power, signals, and communication between the pendant and the controller so the operator can jog, program, and monitor the robot.
These cables are available in multiple fixed lengths. Always match the exact part number including the length suffix to your existing cable or controller requirements. Using the wrong length or connector variant can prevent proper communication or create safety issues.
A660-2006-T324L
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| Pendant will not power on | Cable fault or poor connection | ✅ High | Inspect both ends and try a known-good cable | Replace cable; check controller power |
| Intermittent communication | Damaged conductors or bent pins | ✅ High | Wiggle test while monitoring pendant | Replace cable; avoid sharp bends and strain |
| Pendant boots but no robot control | Wrong cable variant or length mismatch | ✅ High | Compare exact part number and connectors | Verify correct length and connector style |
| Error on controller after connect | Short or open in cable | ✅ High | Visual inspection + continuity test if possible | Replace with tested cable |
| Cable feels stiff or cracked | Age / environmental damage | ✅ Medium | Physical inspection of jacket and strain relief | Replace proactively before failure |
| No issue with short cable, fails with long | Length or signal integrity | ❌ Medium | Test with shorter known-good cable | Confirm correct length specification |
If problems persist, note the exact pendant model, controller type, and any alarm codes displayed.
6. Frequently Asked Questions (FAQ)
Q: What is the A660-2006-T324L used for?
A: It is the cable that connects a FANUC teach pendant (iPendant) to the robot controller so the operator can program and operate the robot.
Q: Are there different lengths?
A: Yes. The base number A660-2006-T324 is followed by a length identifier (for example #L=06M for 6 meters, longer versions such as 10 m, 12 m, or 20 m). Always order the exact length you need.
Q: Will this cable work with any FANUC robot?
A: It is designed for specific controller and pendant combinations (commonly R-30iA / R-30iB series and compatible iPendants). Confirm compatibility with your controller and pendant model before ordering.
Q: Can I repair a damaged teach pendant cable?
A: Field repair is not recommended. These are multi-conductor cables with proprietary connectors. Replacement with a tested OEM or equivalent cable is the reliable solution.
Q: How should I handle and store the cable?
A: Avoid sharp bends, crushing, or pulling on the connectors. Use proper strain relief and keep the cable away from moving robot axes, heat sources, and coolant when possible.
Q: What should I check before ordering a replacement?
A: Photograph both ends of the existing cable, note the full part number including any length suffix, and confirm the pendant and controller models. This prevents ordering an incompatible variant.
Q: Is this cable still available new?
A: Original production status varies by exact length variant. Most available units are new surplus or carefully tested stock. Verify current availability and exact suffix when placing an order.
