3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Function | Emergency overspeed and trip protection |
| Monitoring | Overspeed, flame detection, critical trips |
| Series Compatibility | Mark V turbine control systems |
| Operating Temperature | -30 to 65°C (standard Mark V range) |
| Power | Backplane powered from Mark V rack |
| Response | Fast shutdown on detected faults |
| Board Revision | G1ACB variant |
| Application | Gas and steam turbine safety systems |
| Inputs | Speed signals, flame sensor inputs |
| Outputs | Trip relays and shutdown commands |
4. Product Introduction
The GE DS200TCEAG1ACB is an Emergency Overspeed Board used in GE Speedtronic Mark V turbine control systems. It continuously monitors for overspeed conditions, flame detection issues, and other critical trip parameters to initiate safe turbine shutdown.
This board forms a key part of the Mark V protective system on gas and steam turbines. It delivers independent overspeed protection that operates in parallel with the main control processor, providing the redundancy needed for high-reliability applications. Field teams rely on it for dependable trip logic when primary controls indicate a fault.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No overspeed trip on test | Board fault or wiring issue | ✅ High | Simulate overspeed signal; monitor trip relay output | Replace DS200TCEAG1ACB if no response |
| False trip activation | Sensor noise or board failure | ✅ Medium | Check input signal integrity with scope | Verify sensors first; replace board if clean signal triggers falsely |
| Flame detection failure | Board or sensor problem | ✅ High | Test flame sensor inputs per manual | Isolate to board and replace as needed |
| LED status abnormal | Power or internal fault | ✅ High | Verify 24 V DC supply and board LEDs | Power cycle rack; replace board if LEDs remain off |
| No communication to controller | Backplane connection issue | ❌ Low | Inspect connectors and ribbon cables | Reseat connections before board replacement |
Contact technical support with trip log data, LED status photos, and test results if the issue is not resolved.
- DS200TCEAG1ACB
- DS200TCEAG1ACB
6. Frequently Asked Questions (FAQ)
Is the DS200TCEAG1ACB hot-swappable? No. Shut down the turbine and de-energize the Mark V rack before installing or removing this safety-critical board. Improper handling during operation risks uncontrolled turbine behavior.
What condition is this unit? New Original / New Surplus from OEM inventory. Every board undergoes functional testing in a Mark V simulation environment, including overspeed signal injection and trip verification. Full test reports provided.
Does this serve as a direct replacement? Yes for compatible Mark V systems. Confirm the exact revision and application (gas or steam turbine). Record all existing jumper or configuration settings on the old board and match them on the replacement.
How thoroughly do you test these? We simulate overspeed conditions, flame detection signals, and various trip scenarios. Relay outputs, logic timing, and power integrity are all verified. We use calibrated test equipment and document results for each unit.
Is any configuration or programming needed? Basic jumper settings may need verification to match your system. No software download required for this board. The main Mark V controller handles higher-level integration. Always reference the system-specific drawings.
What warranty do you offer? 1-year warranty covering manufacturing defects and functional performance. Does not cover damage from improper installation, ESD, or operation outside specified parameters.
My system has a different TCEA revision. Will this work? Provide your current board’s full part number and photos. We cross-reference revisions for compatibility. In most Mark V installations, the G1ACB variant serves as a standard replacement when properly configured.
