GE Fanuc IC693PBM200-FE Series 90-30 PROFIBUS DP Master Module

Description

Key Technical Specifications

Product Introduction & Supply Chain Strategy

The GE Fanuc IC693PBM200-FE is a dedicated PROFIBUS DP Master module engineered for Series 90-30 PLCs. It enables high-speed fieldbus connectivity between the central PLC host and up to 125 PROFIBUS DP slave devices—such as variable frequency drives, motor control centers, valve manifolds, and remote field I/O nodes.

Securing the IC693PBM200-FE as New Surplus is a high-value strategy for plants maintaining active Series 90-30 architectures with fieldbus networks. Sourcing uninstalled, factory-fresh original inventory eliminates the elevated risks of RS-485 transceiver degradation, baud-rate timing instability, and backplane bus errors common in second-hand cards, preserving plant productivity without requiring a full PLC platform migration.

IC693PBM200-FE

IC693PBM200-FE

Installation & Configuration Guide

Stage 1: Pre-Installation (Prep & Safety)

1. Execute Lock-Out/Tag-Out (LOTO) procedures on the power source supplying the PLC rack.
2. Put on an anti-static grounded wrist strap to protect high-speed fieldbus transceivers and memory ICs from ESD damage.
3. Verify that the PROFIBUS network cable is terminated correctly with standard 220 Ω termination resistors enabled at both physical ends of the segment.

Stage 2: Removal

1. De-energize the baseplate rack power supply.
2. Unscrew and disconnect the 9-pin DB-9 PROFIBUS network connector from the front panel.
3. Squeeze the module release levers at the top and bottom of the card and pull it straight forward out of the baseplate slot.

Stage 3: Installation (Seat & Wire)

1. Position the rear card edge of the replacement IC693PBM200-FE into any available Option/I/O slot of a Series 90-30 main or expansion baseplate.
2. Press firmly on the top and bottom face of the module housing until both retaining latches click locked.
3. Plug the 9-pin PROFIBUS cable connector into the front port and tighten the thumb retaining screws securely.

Stage 4: Power-On & Testing

1. Reapply main power to the PLC rack and fieldbus devices.
2. Check that the “MODULE OK” status LED lights solid green, and the “COMM” indicator flashes or stays solid green once cyclic data exchange begins.
3. Use Proficy Machine Edition or the PROFIBUS Configuration Tool (GSD files) to verify bus communications and confirm zero packet drop errors on connected slave nodes.

Firmware/Software Versions & Upgrade Notes

• Revision Compatibility: The “-FE” suffix represents the hardware and firmware manufacturing revision. Revision FE provides enhanced baud rate auto-detection and expanded GSD file handling over earlier releases (e.g., AA through ED).
• Software Configuration: Configured using Proficy Machine Edition (PME) along with the integrated PROFIBUS Configuration Tool. GSD (General Station Description) files for all connected slave devices must be imported into the project library.
• CPU & Firmware Dependencies: Requires a modular CPU (such as CPU350, CPU352, CPU360, CPU364, or CPU374) running firmware version 9.0 or higher to support full dual-port block transfer buffers.

Frequently Asked Questions (FAQ)

Is this IC693PBM200-FE module brand new or pulled from a used rack?

This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo complete quality verification to ensure OEM-level performance.

What is the primary operational benefit of sourcing New Surplus for fieldbus master modules?

Fieldbus master cards process continuous high-frequency serial transmissions at up to 12 Mbps. Refurbished or pulled modules frequently suffer from degraded RS-485 line driver ICs, weak optical isolators, and thermal stress cracks that cause intermittent bus dropouts. Sourcing New Surplus guarantees original signal timing and 100% component life.

What quality control steps are completed prior to shipment?

Every IC693PBM200-FE undergoes a comprehensive QC protocol, including serial number verification, physical backplane connector inspection, power-on self-test (POST) execution, and live loopback test rack verification.

What is the difference between the (Master) and IC693PBS201 (Slave)?

The is a PROFIBUS DP Master module that controls network polling and manages slave devices. The IC693PBS201 is a PROFIBUS DP Slave module, which allows the Series 90-30 PLC to act as a subordinate device controlled by an external master PLC.

Does this module support PROFIBUS DP-V1 acyclic messaging?

Yes. Revision FE fully supports DP-V1 acyclic parameter read/write services in addition to standard DP-V0 cyclic I/O data exchange, allowing remote drive parameterization and diagnostic alarm retrieval.

What warranty coverage is included with this New Surplus module?

This module includes a full 1-year functional warranty. If any operational defect or hardware failure occurs during normal use within 12 months, we will immediately supply a replacement unit from our active buffer inventory.
