3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Inputs | 40 x 24 VDC |
| Outputs | 24 relay outputs |
| Power Supply | 24 VDC |
| User Memory | Sufficient for small-medium applications |
| Communication Ports | Serial ports (RS-232/RS-485) |
| Operating Temperature | 0 to 60°C |
| Expansion | Supported via option modules |
| Mounting | DIN rail |
4. Product Introduction
The GE Fanuc IC200UDR064 is a VersaMax Micro PLC with 40 DC inputs and 24 relay outputs. It combines control logic, I/O, and power supply in a compact unit for machine and process automation.
This 64-point Micro controller is ideal for standalone or distributed applications requiring reliable relay outputs for loads up to 2 A. It supports expansion and standard programming tools.
- IC200UDR064
- IC200UDR064
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No power | Supply voltage missing | ✅ High | Measure 24 VDC at terminals | Verify input power |
| Inputs not reading | Wiring or configuration | ✅ High | Monitor in programming software | Check wiring polarity |
| Outputs not activating | Load or relay fault | ✅ High | Test with multimeter | Check coil/load; replace if needed |
| Communication failure | Cable or port settings | ✅ Medium | Test serial connection | Verify baud rate and cable |
| Program not running | Fault or memory issue | ✅ High | Check PLC status | Clear faults and reload program |
Contact technical support with project files and error codes.
6. Frequently Asked Questions (FAQ)
Is the IC200UDR064 hot-swappable? No. Power down before servicing.
What are the I/O counts? 40 x 24 VDC inputs and 24 relay outputs.
Condition of the unit? New Original / New Surplus.
Programming software? Proficy Machine Edition or compatible VersaMax tools.
Output rating? Relay outputs rated 2 A at 24 VDC / 240 VAC.
Warranty? 1-year warranty.
Expansion capability? Yes, supports option modules for additional I/O and communications.
