3. Key Technical Specifications
- Processor: 600 MHz Pentium-M
- User Memory: 64 MB battery-backed RAM
- Non-Volatile Memory: 64 MB flash
- I/O Capacity: Up to 32K discrete bits, 32K words analog
- Embedded Ethernet: 10/100 Mbps
- Serial Ports: RS-232, RS-485
- Operating Temperature: 0 to 60°C
- Floating Point: Yes
- Programming Languages: Ladder, ST, FBD, C
- Backplane: VME-based RX7i rack
4. Product Introduction
The GE IC698CPE030 is a 600 MHz Pentium-M CPU for the PACSystems RX7i platform. It provides 64 MB of user memory and 64 MB of flash storage along with embedded Ethernet connectivity.
This CPU delivers high-performance processing for complex control applications, data-intensive tasks, and large-scale automation systems in the RX7i family.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| CPU not powering up | Rack power supply failure | ✅ High | Check power supply LEDs and voltages | Verify/replace rack power supply |
| No Ethernet link | Cable or IP configuration | ✅ High | Check Ethernet LEDs and use ping | Verify IP settings and cable |
| Fault LED on | Program fault or hardware issue | ✅ High | Read fault table in programming software | Analyze and clear faults |
| Slow performance | Memory or program overload | ✅ Medium | Monitor CPU utilization | Optimize application code |
| Battery low alarm | Depleted backup battery | ✅ Medium | Check battery status | Replace CPU battery |
Contact technical support with CPU LED status, fault logs, and project details if issues persist.
- IC698CPE030
- IC698CPE030
6. Frequently Asked Questions (FAQ)
Does the IC698CPE030 have built-in Ethernet? Yes. It includes a 10/100 Mbps Ethernet port for network communication.
How much memory is available? 64 MB of battery-backed user RAM and 64 MB of flash memory for program and data storage.
Can this CPU be used in a redundant configuration? A redundant version (IC698CRE030) exists for hot standby setups. This standard model is for single CPU systems.
What software programs this CPU? Use Proficy Machine Edition to program and configure the RX7i CPU.
Is the CPE030 suitable for large applications? Yes. The 600 MHz processor and large memory make it well-suited for demanding, high I/O count, or computationally intensive projects.
Why choose New Surplus for this CPU? These units are genuine OEM stock that were never installed in the field. They receive full functional testing and offer cost savings compared to current lead times for RX7i hardware.
What should I prepare before swapping the CPU? Backup your complete project, document IP settings and serial configurations, note battery status, and have a replacement battery ready. Take photos of the existing setup.
