Key Technical Specifications
| Parameter | Specification |
| Full Part Number | ABX-EMBS-PDPS |
| Manufacturer | HMS Industrial Networks (Anybus) |
| EtherNet/IP Interface | 10/100 Mbps RJ45 port (Supports Scanner/Master or Adapter mode) |
| PROFIBUS Interface | 9-pin D-sub female connector (PROFIBUS DP-V0 / DP-V1 Slave) |
| Baud Rate (PROFIBUS) | Auto-baud detection up to 12 Mbps |
| I/O Data Capacity | Up to 512 bytes input and 512 bytes output data transfer |
| Input Power Supply | 24 VDC ±10% (Typical current draw 150 mA at 24V) |
| Configuration Interface | USB / RS-232 serial via Anybus Configuration Manager |
| Housing & Mounting | Rugged aluminum IP20 enclosure, 35mm DIN-rail mountable |
| Operating Temperature | -25°C to +65°C (-13°F to 149°F) |
Product Introduction & Supply Chain Strategy
The HMS Anybus ABX-EMBS-PDPS is an industrial X-gateway engineered to bridge EtherNet/IP control networks with legacy PROFIBUS DP fieldbus systems. Acting as a transparent protocol translator, it allows modern Allen-Bradley / Rockwell Logix PLCs on EtherNet/IP to exchange real-time I/O data with Siemens or European PROFIBUS DP slave drives and field devices without requiring costly PLC programming rewrites.
This product is a Brand New Surplus unit. It is not used, not pulled from a decommissioned plant, and not refurbished. All modules undergo rigorous quality verification to ensure OEM-level reliability.
Securing an ABX-EMBS-PDPS gateway as New Surplus offers vital Total Cost of Ownership (TCO) protection for process automation engineers. Network gateways are critical single-point failure nodes; buying second-hand or refurbished units exposes your network to aged power supply regulation circuits and worn serial interfaces that drop packets under heavy EMI load. Saving 300 on a refurbished gateway can cost 50,000 in unplanned downtime when a communication drop halts a whole packaging line. We recently saw a beverage bottling facility attempt to save procurement budget by buying a second-hand fieldbus gateway. Three months later, internal memory corruption triggered intermittent PROFIBUS bus faults, halting the line for 12 hours. Our pricing reflects the true cost of securing pristine New Surplus inventory globally, guaranteeing 100% data throughput and total operational peace of mind.
ABX-EMBS-PDPS
ABX-EMBS-PDPS
Installation & Configuration Guide
- Stage 1: Pre-Installation (Prep & Safety)
Disconnect 24 VDC power feeds to the panel enclosure using lock-out/tag-out procedures. Put on a grounded ESD wristband. Obtain the GSD file for the PROFIBUS slave configuration and prepare the Anybus Configuration Manager software on a field laptop.
- Stage 2: Removal
Unplug the 2-pin removable terminal block for 24 VDC power. Unscrew the DB9 PROFIBUS cable and disconnect the RJ45 EtherNet/IP patch cord. Release the lower DIN-rail locking tab using a flat-head screwdriver and unhook the old module from the rail.
- Stage 3: Installation (Clone & Seat)
Snap the New Surplus ABX-EMBS-PDPS module onto the 35mm DIN rail until the spring latch engages securely. Connect the DB9 PROFIBUS cable (ensuring bus termination resistors are set ON at line ends). Plug in the RJ45 Ethernet cable and wire the 24 VDC power terminal block observing correct polarity.
- Stage 4: Power-On & Testing
Apply 24 VDC power. Observe the front LED indicators: confirm the Power LED is green, the EtherNet/IP (MS/NS) LEDs show solid green connection status, and the PROFIBUS (FB) LED transitions from red to solid green to indicate an active fieldbus exchange with the master controller.
Firmware/Software Versions & Upgrade Notes
- Configuration Management: Use Anybus Configuration Manager (X-gateway version) to upload the I/O mapping profile from the original unit and download it to the replacement gateway via the USB/serial port.
- GSD File Integration: Verify that the PROFIBUS DP Master PLC software (e.g., Siemens STEP 7 or TIA Portal) utilizes the exact matching GSD file version corresponding to the ABX-EMBS-PDPS profile.
- Modification Warning: Never disconnect network trunk cables or clear device memory while the gateway is actively mapping process data. Interrupting communication while writing configuration files can corrupt the internal memory table, requiring a factory recovery reset.
Frequently Asked Questions (FAQ)
- Q: Is this HMS Anybus ABX-EMBS-PDPS gateway brand new surplus or a used module?
A: This unit is 100% Brand New Surplus. It is not used, not pulled from a decommissioned plant, and not refurbished. It features unblemished terminal connectors, untouched DIN-rail clips, and pristine internal circuitry.
- Q: Why should I choose New Surplus over a refurbished gateway online?
A: Refurbished network gateways frequently suffer from degraded power capacitors and heat-stressed processing chips. A network failure on an industrial gateway stops data transfer across entire control networks, leading to massive production line outages that far exceed the cost savings of buying used parts.
- Q: Does this unit require software configuration before deployment?
A: Yes, the module requires I/O data size mapping (defining input/output byte lengths between EtherNet/IP and PROFIBUS) using the free Anybus Configuration Manager utility before it will establish fieldbus data exchanges.
- Q: Can this module act as both an EtherNet/IP Master and a PROFIBUS Slave simultaneously?
A: Yes, the ABX-EMBS-PDPS configuration supports EtherNet/IP Originator/Scanner capabilities while simultaneously functioning as a standard PROFIBUS DP-V0/V1 Slave node on the fieldbus side.
- Q: What warranty coverage applies to this New Surplus HMS gateway?
A: We provide a comprehensive 1-year replacement warranty on this New Surplus unit, ensuring full operational reliability for your automation infrastructure.
